Plan 22104SL
Two Bedroom Carriage House Plan
Heated S.F.
1,128
Beds
2
Baths
1
Stories
1
Cars
3
What's Included
Plan Details
  • Are you looking for extra space to park the family cars and in-law or guest quarters? Check out this three-car carriage house plan with two bedrooms.
  • The garage area features 988 square feet of sheltered parking, three 9'x7' overhead doors and stairs leading to the living quarters above.
  • An open kitchen and living area greet you upstairs as well as two bedrooms a bath and laundry.
  • Related Plans: Get an alternate exterior with carriage house plan 22105SL.
  • For a one bedroom version see carriage house plan 22116SL.
  • Finish the upstairs later with garage plan 22073SL with an unfinished loft space.
What's Included
  • Foundation plan
  • Fully dimensioned floor plans
  • Exterior elevations
  • Roof plan
  • Electrical plan
  • Cabinet elevations
  • Building section
  • Typical stair and wall sections and other related details
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Two Bedroom Carriage House Plan

  • 1,128

    Heated s.f.

  • 2

    Beds

  • 1

    Baths

  • 1

    Floors

  • 3

    Car garage

Floor Plan

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 1,128 sq. ft.
  • 1st Floor: 1,128 sq. ft.

Dimensions

  • Width: 42' 0"
  • Depth: 28' 0"
  • Max ridge height: 26' 0"

Beds/Baths

  • Bedrooms: 2
  • Full bathrooms: 1

Garage

  • Type: Detached
  • Area: 988 sq. ft.
  • Count: 3 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 8' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 8 on 12
  • Secondary Pitch: 6 on 12
  • Framing Type: Truss
