Plan 444404GDN: 2 Bed House Plan Under 1000 Square Feet with Open and Vaulted Interior

Plan 444404GDN

2 Bed House Plan Under 1000 Square Feet with Open and Vaulted Interior

Heated S.F.

984

Beds

Baths

Stories

Floor Plan

Main Level

Plan Details

This 984 square foot house plan features a board-and-batten façade with decorative gable trusses and a vaulted-and-open interior greeting as you enter the home from the front or the back.
The front porch leads to an open floor plan with a cathedral ceiling extending from the great room to the dining space and island kitchen. Living continues outdoors with a screened porch and patio.
The master suite enjoys a vaulted ceiling, walk-in closet, and efficient private bathroom. A secondary bedroom and bathroom are joined by a utility space with linen storage.
Skylights bring natural light into the main living space while sun tunnels brighten the master bathroom and utility room.
Delivery Delay Notes:
Please allow 8 weeks for delivery if it includes the slab foundation option.
Please allow 10 weeks for delivery if it includes the basement foundation option.
Please allow 8 weeks for delivery if it includes 2x6 exterior wall conversion option.

What's Included

Cover Sheet - An artist's rendering of the exterior of the house shows you approximately how the house will look when built and landscaped
Foundation Plan - This plan gives the foundation layout, including support walls, excavated and unexcavated areas, if any, foundation notes and details, and floor framing.
Detailed Floor Plans - These plans show the layout of each floor of the house. Rooms and interior spaces are carefully dimensioned and keys are given for cross-section details provided later in the plans, as well as window and door schedules. These plans may also show the location of kitchen appliances and plumbing fixtures, and may suggest locations for electrical fixtures, switches and outlets.
Interior Elevations - The interior elevation drawings show a suggested layout design of cabinets, utility rooms, fireplaces, bookcases, built-in units and other special interior features depending on the nature and complexity of the item.
Roof Plan - The roof plan shows a bird's eye view of the overall layout of the roof, ridges, valleys, and slopes.
Exterior Elevations - Included are front, rear, left and right sides of the house. Exterior materials, details and measurements are also given.
Cross-Section / Wall Section Details - Important changes in floor, ceiling and roof heights or the relationship of one level to another are called out. Also shown, when applicable, are exterior details such as railing and banding.
Structural Plan - Overall layout and necessary details for the ceiling, second-floor framing (if applicable) and roof construction. If trusses are used, it's suggested that you use a local truss manufacturer to design your trusses to comply with your local codes and regulations.

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
