2402 Square Foot 2-Bed Mountain Craftsman House Plan with Lower Level Expansion
Heated S.F.
2,402
Beds
2-4
Baths
2.5 - 3.5
Stories
1
Cars
3
What's Included
Floor Plan
PRINT PLANS
Main Level
Reverse Floor Plan
2402 Square Foot 2-Bed Mountain Craftsman House Plan with Lower Level Expansion - 849015PGE floor plan - Main Level
Unfinished Basement
Reverse Floor Plan
2402 Square Foot 2-Bed Mountain Craftsman House Plan with Lower Level Expansion - 849015PGE floor plan - Unfinished Basement
Plan Details
  • This mountain Craftsman house plan gives you 2 bedrooms and 2,402 square feet of heated living with an optional to finished lower level - included with plan purchase - that gives you 2 more bedrooms and 2,355 square feet of expansion space.
  • A 3-car garage has a one-car bay and a two-car bay and gets you 919 square feet of parking space.
  • The great room has a vaulted ceiling and a fireplace o the back wall. It is open to the kitchen with large island a true walk-in pantry.
  • Sliding doors in the dining room open to the large rear deck.
  • A split bedroom layout places the master suite on the left with laundry conveniently located nearby and Bed 2 across the home with direct access to a bath which also is accessible from the entry hall.
What's Included
  • Cover Sheet
  • Elevations
  • Foundation Plan
  • Floor Plan
  • Details and Schedules
  • Upper Floor Framing Plan
  • Roof Flaming Plan
  • Details
  • Sections and Notes
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical and Electrical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

2402 Square Foot 2-Bed Mountain Craftsman House Plan with Lower Level Expansion

  • 2,402

    Heated s.f.

  • 2-4

    Beds

  • 2.5 - 3.5

    Baths

  • 1

    Floors

  • 3

    Car garage

Floor Plan

  • Main Level

  • Unfinished Basement

Plan Details

Square Footage Breakdown

  • Total: 2,402 sq. ft.
  • 1st Floor: 2,402 sq. ft.

Dimensions

  • Width: 73' 5"
  • Depth: 59' 6"
  • Max ridge height: 22' 7"

Beds/Baths

  • Bedrooms: 2, 3, or 4
  • Full bathrooms: 2 or 3
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 919 sq. ft.
  • Count: 3 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Basement, Walkout
    • Optional Foundations: Slab, Crawl

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: Lower Level / 9' 0" First Floor / 9' 0"

Roof

  • Primary Pitch: 10 on
  • Secondary Pitch: 5 on
  • Framing Type: Truss
