3-Bed Transitional Tudor Home Plan with Optional Bonus Room above Garage

Plan 93185EL

  • 2,103

    Heated s.f.

  • 3

    Beds

  • 2.5

    Baths

  • 1

    Stories

  • 2

    Cars

  • Sweeping roof lines and an arched entryway add a softness to the exterior of this Transitional Tudor home plan that delivers 3 bedrooms and 2.5 baths.
  • The open-concept design creates a family-friendly environment and glass sliders extend the living space onto a 17' by 14' covered porch.
  • A pocket office with natural light is tucked behind the kitchen and a mudroom next to the double garage organizes your shoes and outerwear.
  • The serene primary bedroom is located across the hall from the laundry room and includes a 2-person shower and walk-in closet in the ensuite.
  • Two family bedrooms share a Jack-and-Jill bathroom towards the front of the design, and an optional bonus room above the garage provides a flexible space to round out the home.

Each plan set includes the following:

  • Cover Sheet
  • General Note Sheet
  • Foundation Sheet
  • First Floor Plan
  • Second Floor Plan (if applicable)
  • Roof Framing Plan
  • Front & Rear Elevation
  • Left & Right Elevation
  • Openings & Sections Sheet
  • Foundation Details
  • Cornice Details
  • First Floor Electrical
  • Second Floor Electrical (if applicable)
These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
3-Bed Transitional Tudor Home Plan with Optional Bonus Room above Garage - 93185EL floor plan - Main Level

2nd Floor

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
3-Bed Transitional Tudor Home Plan with Optional Bonus Room above Garage - 93185EL floor plan - 2nd Floor

Plan details

Square Footage Breakdown

  • Total Heated Area: 2,103 sq. ft.
  • 1st Floor: 2,103 sq. ft.
  • Porch, Rear: 223 sq. ft.
  • Porch, Front: 66 sq. ft.
  • Bonus: 339 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2
  • Half bathrooms: 1

Foundation Type

  • Standard Foundations: Crawl
  • Optional Foundations: Walkout, Slab, Daylight, Basement

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 61' 2"
  • Depth: 63' 10"
  • Max ridge height: 27' 5"

Garage

  • Type: Attached
  • Area: 572 sq. ft.
  • Count: 2 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: First Floor / 10' 0"

Architectural Style

Special features

Plan Collections

3-Bed Transitional Tudor Home Plan with Optional Bonus Room above Garage

  • 2,103

    Heated s.f.

  • 3

    Beds

  • 2.5

    Baths

  • 1

    Floors

  • 2

    Car garage

Buy This Plan
  • PDF - Single-Build $1,600
  • CAD+PDF - Single-Build $1,900
  • PDF - Unlimited Build $2,450
  • CAD - Unlimited Build $2,750
  • View all purchase option online

About This Plan

  • Sweeping roof lines and an arched entryway add a softness to the exterior of this Transitional Tudor home plan that delivers 3 bedrooms and 2.5 baths.
  • The open-concept design creates a family-friendly environment and glass sliders extend the living space onto a 17' by 14' covered porch.
  • A pocket office with natural light is tucked behind the kitchen and a mudroom next to the double garage organizes your shoes and outerwear.
  • The serene primary bedroom is located across the hall from the laundry room and includes a 2-person shower and walk-in closet in the ensuite.
  • Two family bedrooms share a Jack-and-Jill bathroom towards the front of the design, and an optional bonus room above the garage provides a flexible space to round out the home.

Floor Plans

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total Heated Area: 2,103 sq. ft.
  • 1st Floor: 2,103 sq. ft.
  • Porch, Rear: 223 sq. ft.
  • Porch, Front: 66 sq. ft.
  • Bonus: 339 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2
  • Half bathrooms: 1

Foundation Type

    • Standard Foundations: Crawl
    • Optional Foundations: Walkout, Slab, Daylight, Basement

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 61' 2"
  • Depth: 63' 10"
  • Max ridge height: 27' 5"

Garage

  • Type: Attached
  • Area: 572 sq. ft.
  • Count: 2 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: First Floor / 10' 0"
