5-Bed Transitional House Plan with Finished Basement
Heated S.F.
5,571
Beds
5
Baths
4.5+
Stories
2
Cars
2
What's Included
Plan Details
  • This 5-bedroom Transitional house plan with European influences showcases timber-framed gables and a brick exterior.
  • Designed with entertaining in mind, this floor plan features a sizable living area that expands onto a partially-screened outdoor space, generous dining room to host large gatherings, and a game room in the basement with a full kitchenette.
  • Large service areas include a mudroom with builtin lockers, neighboring laundry room, and a sizable walk-in pantry.
  • Enjoy the convenience of a main-floor master bedroom, crowned by a tray ceiling, and paired with a 5-fixture bathroom and a walk-in closet.
  • The kids will appreciate the home theater and game room upstairs, as well as the playroom just off the kitchen. A second laundry room upstairs is a helpful addition and a home office is ideal for the work-at-home resident.
What's Included

  • Cover page
  • Foundation plan
  • Floor Plan
  • Elevations
  • Section View
  • Construction details
  • Electrical Layout
  • and Roof Plan if needed
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
