500 Square Foot Outdoor Kitchen Pavilion

Heated S.F.
0
Beds
0
Baths
0
Stories
1

Floor Plan

Plan 61456UT

Main Level
Main Level

Plan 61456UT

M-F 9am-5pm EST |

1-203-761-8500

Main Level

Plan 61456UT: 500 Square Foot Outdoor Kitchen Pavilion - Floor Plan - Main Level - Craftsman, Traditional

Plan Details

  • Four timber supports are set in attractive brick bases and define the 25' by 20' footprint of this 500 square foot outdoor kitchen pavillion.
  • The kitchen lines one side and sits under a vaulted ceiling.
  • This makes a great addition to your back yard and is a wonderful space for parties and gatherings with friends and family.

What's Included

  • General notes
  • Foundation plan
  • Detailed floor plans
  • Floor framing
  • Roof framing
  • Elevations
  • Cross sections
  • Electrical plans
  • General details
View Sample Plan

What's Not Included

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Starting at
