Plan 61457UT
6000 Square Foot Car Lover's Garage with Drive Through RV Bay and a Clean-Up Bath with Shower
Heated S.F.
56
Beds
0
Baths
1
Stories
1
Cars
8
What's Included
Plan Details
  • This garage plan has 4 bays with 10' by 12' overhead doors and a fifth RV bay - drive-through, no less - with a 12' by 14' overhead door. A sixth bay with a 10' by 12' overhead door is in back. All together, there is 6,000 square feet of vehicle space inside.
  • An L-shaped porch wraps around the back-left corner.
  • Two sinks are by the back porch access door and a full bath is tucked away in the back-left corner giving you a spot to clean up after working on your vehicles.

What's Included
  • General notes
  • Foundation plan
  • Detailed floor plans
  • Floor framing
  • Roof framing
  • Elevations
  • Cross sections
  • Electrical plans
  • General details
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

6000 Square Foot Car Lover's Garage with Drive Through RV Bay and a Clean-Up Bath with Shower

  • 56

    Heated s.f.

  • 0

    Beds

  • 1

    Baths

  • 1

    Floors

  • 8

    Car garage

Floor Plan

  • Main Level

Plan Details

Square Footage Breakdown

  • Total: 56 sq. ft.
  • 1st Floor: 56 sq. ft.

Dimensions

  • Width: 108' 0"
  • Depth: 68' 0"
  • Max ridge height: 29' 4"

Beds/Baths

  • Bedrooms: 0
  • Full bathrooms: 1

Garage

  • Type: RV Garage, Detached
  • Area: 6000 sq. ft.
  • Count: 8 Cars
  • Entry Location: Rear, Front

Foundation Type

    • Standard Foundations: Stem Wall

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 16' 0"

Roof

  • Primary Pitch: 5 on 12
  • Secondary Pitch: 6 on 12
  • Framing Type: Truss
