Plan 430825SNG 750 Square Foot Farmhouse-style ADU with 2-Story Living Room

750 2 2 2
Print
Compare HIDE
All plans are copyrighted by our designers. Photographed homes may include modifications made by the homeowner with their builder.

750 Square Foot Farmhouse-style ADU with 2-Story Living Room

Plan 430825SNG

  • 750

    Heated s.f.

  • 2

    Beds

  • 2

    Baths

  • 2

    Stories

  • A symmetrical farmhouse facade with a 5'11"-deep front porch spanning the front with 3 functioning windows bringing in light to the home in the gable large give this 750 square foot ADU or guest cottage classic appeal.
  • The main floor consists of a 2-story living room open to the kitchen with angled peninsula with seating for two.
  • There is one bedroom and bath per floor, and attic space above gives you storage.

The plan set includes the following:

  • Exterior elevations: Included are front, rear, left and right side views of the exterior of the house. Exterior materials, construction details and measurements are also noted.
  • Foundation Plan: Includes layout of foundation support walls, plus excavated and unexcavated areas, if applicable.
  • Detailed Floor Plans: These plans show the layout of each floor of the house, including room dimensions, window and doors sizes and keys for cross section details provided later in the plans. Engineered floor joist, ceiling joist and roof plans are not included in some plans. Local engineers or manufacturing engineers are widely available to supply the services that apply to local geographic conditions.
  • Interior Details: These drawings show the specific details and design of special interior features.
  • Roof Plan: Includes the overall layout for roof construction. If trusses are used, we recommend using a local truss manufacturer to ensure compliance with local codes and regulations.
  • Cross Section Detail: Important changes in floor, ceiling and roof heights or the relationship of one level to another are called out. Exterior details such as railing and banding may also be shown.
  • Electrical: Electrical floor plan schematics for 1st and 2nd floors.

 These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Framing plans
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
750 Square Foot Farmhouse-style ADU with 2-Story Living Room - 430825SNG floor plan - Main Level

2nd Floor

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
750 Square Foot Farmhouse-style ADU with 2-Story Living Room - 430825SNG floor plan - 2nd Floor

Plan details

Square Footage Breakdown

  • Total Heated Area: 750 sq. ft.
  • 1st Floor: 555 sq. ft.
  • 2nd Floor: 195 sq. ft.
  • Porch, Front: 133 sq. ft.

Beds/Baths

  • Bedrooms: 2
  • Full bathrooms: 2

Foundation Type

  • Standard Foundations: Slab
  • Optional Foundations: Crawl, Basement

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 27' 9"
  • Depth: 20' 1"
  • Max ridge height: 22' 2"

Ceiling Heights

  • Floor / Height: First Floor / 8' 0" Second Floor / 8' 0"

Roof Details

  • Primary Pitch: 10 on 12
  • Secondary Pitch: 3 on 12
  • Framing Type: Stick

Architectural Style

Special features

Plan Collections

750 Square Foot Farmhouse-style ADU with 2-Story Living Room

  • 750

    Heated s.f.

  • 2

    Beds

  • 2

    Baths

  • 2

    Floors

Buy This Plan
  • PDF - Single-Build $800
  • CAD - Unlimited Build $1,200
  • View all purchase option online

About This Plan

  • A symmetrical farmhouse facade with a 5'11"-deep front porch spanning the front with 3 functioning windows bringing in light to the home in the gable large give this 750 square foot ADU or guest cottage classic appeal.
  • The main floor consists of a 2-story living room open to the kitchen with angled peninsula with seating for two.
  • There is one bedroom and bath per floor, and attic space above gives you storage.

Floor Plans

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total Heated Area: 750 sq. ft.
  • 1st Floor: 555 sq. ft.
  • 2nd Floor: 195 sq. ft.
  • Porch, Front: 133 sq. ft.

Beds/Baths

  • Bedrooms: 2
  • Full bathrooms: 2

Foundation Type

    • Standard Foundations: Slab
    • Optional Foundations: Crawl, Basement

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 27' 9"
  • Depth: 20' 1"
  • Max ridge height: 22' 2"

Ceiling Heights

  • Floor / Height: First Floor / 8' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 10 on 12
  • Secondary Pitch: 3 on 12
  • Framing Type: Stick
Plan 430825SNG
