Plan 61210UT ADU Garage Apartment with a 1.5 Baths

ADU Garage Apartment with a 1.5 Baths

Plan 61210UT

  • 643

    Heated s.f.

  • 1

    Beds

  • 1.5

    Baths

  • 2

    Stories

  • 2

    Cars

  • The main floor of this garage apartment has room for 2 cars and a half bath in back, great for cleaning up after working on your cars.
  • Upstairs, you'll find a 1-bed apartment complete with a living room open to the kitchen in the front portion and the bedroom with bath and walk-in closet in the back.
  • This could be great as an ADU, a rental apartment or a home office.

Each plan set includes the following:


  • General notes
  • Foundation plan
  • Detailed floor plans
  • Floor framing
  • Roof framing
  • Elevations: front, left, rear, right
  • Cross sections
  • Electrical plans
  • General details
These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
ADU Garage Apartment with a 1.5 Baths - 61210UT floor plan - Main Level
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
ADU Garage Apartment with a 1.5 Baths - 61210UT floor plan - 2nd Floor

Plan details

Architectural Style

Plan Collections

ADU Garage Apartment with a 1.5 Baths

  • 643

    Heated s.f.

  • 1

    Beds

  • 1.5

    Baths

  • 2

    Floors

  • 2

    Car garage

Buy This Plan
  • 5 Sets $665
  • PDF - Unlimited Build $715
  • CAD - Unlimited Build $815
  • 5 Sets + PDF $865
  • CAD Unlimited + PDF $915
  • View all purchase option online

About This Plan

  • The main floor of this garage apartment has room for 2 cars and a half bath in back, great for cleaning up after working on your cars.
  • Upstairs, you'll find a 1-bed apartment complete with a living room open to the kitchen in the front portion and the bedroom with bath and walk-in closet in the back.
  • This could be great as an ADU, a rental apartment or a home office.

Floor Plans

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total Heated Area: 643 sq. ft.
  • 2nd Floor: 643 sq. ft.

Beds/Baths

  • Bedrooms: 1
  • Full bathrooms: 1
  • Half bathrooms: 1

Foundation Type

    • Standard Foundations: Stem Wall

Exterior Walls

  • Standard Type(s): 2x4

Dimensions

  • Width: 21' 0"
  • Depth: 30' 0"
  • Max ridge height: 23' 10"

Garage

  • Type: Detached
  • Area: 643 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Ceiling Heights

  • Floor / Height: First Floor / 10' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 5 on 12
  • Framing Type: Truss
