Plan 59891ND Charming Home Plan with Columns and Dormers

Charming Home Plan with Columns and Dormers

Plan 59891ND

  • 2,424

    Heated s.f.

  • 4

    Beds

  • 3

    Baths

  • 1

    Stories

  • 3

    Cars

  • Columns and dormers add to the charm of this four bedroom home plan.
  • Bookshelves flank the foyer.
  • Columned entries enhance the great and dining rooms.
  • The well-planned kitchen packed with amenities.
  • This design gives the master suite the privacy of its own side of the home plan while the other three bedrooms are tucked away on the other side.

Each plan set includes the following:

  • Foundation Plan** (1/4″ or 1/2″ = 1′)
  • Floor Plans (1/4″= 1′)
  • Set of Elevations (1/4″= 1′)
  • Building Sections (1/4″ or 1/2″ = 1′)
  • Kitchen and Bath Elevations (1/2″ = 1′)
  • Miscellaneous Details (3/4″ = 1′)
  • An electrical diagram showing a Birdseye view of rooms with lights, fans to switches
These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Charming Home Plan with Columns and Dormers - 59891ND floor plan - Main Level

Plan details

Architectural Style

Charming Home Plan with Columns and Dormers

  • 2,424

    Heated s.f.

  • 4

    Beds

  • 3

    Baths

  • 1

    Floors

  • 3

    Car garage

Buy This Plan
  • PDF - Single-Build $1,000
  • 5 Sets $1,100
  • 5 Sets + PDF $1,350
  • CAD - Single-Build $2,000
  • View all purchase option online

About This Plan

  • Columns and dormers add to the charm of this four bedroom home plan.
  • Bookshelves flank the foyer.
  • Columned entries enhance the great and dining rooms.
  • The well-planned kitchen packed with amenities.
  • This design gives the master suite the privacy of its own side of the home plan while the other three bedrooms are tucked away on the other side.

Floor Plans

  • Main Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 2,424 sq. ft.
  • 1st Floor: 2,424 sq. ft.
  • Porch, Rear: 362 sq. ft.
  • Porch, Front: 85 sq. ft.

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 3

Foundation Type

    • Standard Foundations: Crawl, Slab
    • Optional Foundations: Basement, Walkout

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 70' 2"
  • Depth: 86' 8"
  • Max ridge height: 21' 4"

Garage

  • Type: Attached
  • Area: 1060 sq. ft.
  • Count: 3 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof

  • Primary Pitch: 8 on 12
  • Framing Type: Stick
