Plan 59331ND
Covered Porch Duplex
Heated S.F.
4,364
Units
2
Width
84'
Depth
62' 4"
Cars
4
What's Included
Plan Details
  • Picture staring into the warm orange sunset from the covered porch of this home. On those cool autumn evenings, you will be able to sip your cocoa in front of the built-in fireplace in the spacious great room.
  • ntertaining will be a breeze with the exquisite dining room with eight inch columns.
  • Spending quality time with your family will be heart felt in the convenient kitchen, and hearth room with fireplace and atrium door leading to the grilling porch.
  • After the kids are tucked in, you'll find peace in the master suite, or relax in the whirlpool tub.
  • Upstairs, you'll have your choice of a third bedroom or maybe a game room with it's own bath and built-in computer desk.
Unit A
2,182 Sq. Ft.
1768 Sq. Ft. 1st Floor
414 Sq. Ft. 2nd Floor
3 Beds
3 Full Baths
2 Vehicle
Attached
400 Sq. Ft.
42' w 62' 4" d 30' h
Unit B
2,182 Sq. Ft.
1768 Sq. Ft. 1st Floor
414 Sq. Ft. 2nd Floor
3 Beds
3 Full Baths
2 Vehicle
Attached
400 Sq. Ft.
42' w 62' 4" d 30' h
What's Included
  • Foundation Plan** (1/4″ or 1/2″ = 1′)
  • Floor Plans (1/4″= 1′)
  • Set of Elevations (1/4″= 1′)
  • Miscellaneous Details (3/4″ = 1′)
  • An electrical diagram showing a birdseye view of rooms with lights, fans to switches
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Covered Porch Duplex

  • 4,364

    Heated s.f.

  • 2

    Units

  • 84'

    Width

  • 62' 4"

    Depth

Floor Plan

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 4,364 sq. ft.
  • 1st Floor: 3,536 sq. ft.
  • 2nd Floor: 828 sq. ft.

Dimensions

  • Width: 84' 0"
  • Depth: 62' 4"
  • Max ridge height: 30' 2"

Beds/Baths

  • Bedrooms: 6
  • Full bathrooms: 6

Garage

  • Type: Attached
  • Area: 800 sq. ft.
  • Count: 4 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Combo Basement-Crawl, Crawl, Slab

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 9' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 9 on 12
  • Secondary Pitch: 10 on 12
  • Framing Type: Stick
