Plan 89655AH
Craftsman Ranch Home Plan
Heated S.F.
1,509
Beds
3
Baths
2
Stories
1
Cars
2
What's Included
Plan Details
  • In just over 1,500 square feet, you'll get three bedrooms a large living space and extra amenities in this carefully designed Craftsman ranch home plan. Craftsman details give the home plenty of curb appeal allowing it to blend nicely into just about any neighborhood.
  • The kitchen overlooks the dining and great rooms and has direct access to the laundry just off the garage.
  • Two bedrooms share the hall bath are located to your left as you enter, while the master suite is located at the other end of the home for maximum privacy.
  • The two-car garage completes this ranch home plan.
  • Need more room? Gain a finished lower level with house plan 89666AH.
What's Included
  • General Notes
  • Rendering
  • Elevations
  • Fully dimensioned floor plans
  • Foundation
  • Typical wall section & stair section
  • Cross section
  • Cabinet elevations
  • Electrical Plan
  • Roof plan

What's Not Included
  • Architectural or Engineering Stamp
  • Site Plan
  • Mechanical Drawings (location of heating and air equipment and duct work)
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations)
  • Framing layouts with beam sizes and locations
  • Energy calculations
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Craftsman Ranch Home Plan

  • 1,509

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

Plan Details

Square Footage Breakdown

  • Total: 1,509 sq. ft.
  • 1st Floor: 1,509 sq. ft.

Dimensions

  • Width: 49' 0"
  • Depth: 56' 0"
  • Max ridge height: 22' 2"

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2

Garage

  • Type: Attached
  • Area: 469 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Basement
    • Optional Foundations: Slab, Crawl

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof

  • Primary Pitch: 8 on 12
  • Secondary Pitch: 8 on 12
  • Framing Type: Truss
