Duplex Home Plan with European Flair

Plan 89295AH

  • 2,778

    Heated s.f.

  • 2

    Units

  • 82'

    Width

  • 48' 4"

    Depth

  • Stone accents give this traditionally inspired home a European flair that will be enjoyed in almost every neighborhood. With two identical units this duplex house plan provides homeowners with a carefully designed floor plan that makes use of every square inch of space.
  • The kitchen features a breakfast bar that overlooks the adjacent dining and great rooms and creates a living area that's perfect for family gatherings.
  • The master suite, with its walk-in closet and dual sink, is a comfortable retreat. A second bedroom and full bath complete each plan.
  • Additional amenities include a corner fireplace in the great room, nine foot ceilings throughout, and a spacious covered porch off the back of each unit.

Plans include the following:

  • General Notes
  • Rendering
  • Elevations
  • Fully dimensioned floor plans
  • Foundation
  • Typical wall section & stair section
  • Cross section
  • Cabinet elevations
  • Electrical Plan
  • Roof plan

What is NOT included in the plans:

  • Architectural or Engineering Stamp
  • Site Plan
  • Mechanical Drawings (location of heating and air equipment and duct work)
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations)
  • Framing layouts with beam sizes and locations
  • Energy calculations

Unit Details

A
1,389 Sq. Ft.
1389 Sq. Ft. 1st Floor
2 Beds
2 Full Baths
2 Vehicle
Attached
465 Sq. Ft.
41' w 48' 4" d 25' 8" h
B
1,389 Sq. Ft.
1389 Sq. Ft. 1st Floor
2 Beds
2 Full Baths
2 Vehicle
Attached
465 Sq. Ft.
41' w 48' 4" d 25' 8" h
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Duplex Home Plan with European Flair - 89295AH floor plan - Main Level

Duplex Home Plan with European Flair

  • 2,778

    Heated s.f.

  • 2

    Units

  • 82'

    Width

  • 48' 4"

    Depth

Floor Plan

  • Main Level

Plan Details

Square Footage Breakdown

  • Total: 2,778 sq. ft.
  • 1st Floor: 2,778 sq. ft.

Dimensions

  • Width: 82' 0"
  • Depth: 48' 4"
  • Max ridge height: 25' 8"

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 4

Garage

  • Type: Attached
  • Area: 930 sq. ft.
  • Count: 4 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Basement
    • Optional Foundations: Slab, Crawl

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof

  • Primary Pitch: 8 on 12
  • Secondary Pitch: 8 on 12
  • Framing Type: Truss
