Plan 59308ND
Duplex House Plan with Single Family Appeal
Heated S.F.
2,110
Units
2
Width
49' 6"
Depth
54'
Plan Details
  • This duplex house plan gives you side-by-side 1,055 square foot units with the street appeal of a single family home. Each unit delivers 2 beds and 2 baths and have an elegant covered entry.
  • Imagine hosting an exquisite dinner party in the formal dining room separated by columns and base unit with optional storage below and with a pass-through connecting to the kitchen.
  • After dinner, you and your guests can retire to the spacious living room or rear grilling porch and enjoy conversation.
  • When the guests leave, you and your loved one can find relaxation in the master suite with a full bathroom and walk-in closet.
  • The second bedroom will be perfect for guests, or double as a home office.
Unit A
1,055 Sq. Ft.
1055 Sq. Ft. 1st Floor
2 Beds
2 Full Baths
24' 9" w 54' d 22' h
Unit B
1,055 Sq. Ft.
1055 Sq. Ft. 1st Floor
2 Beds
2 Full Baths
24' 9" w 54' d 22' h
What's Included
  • Foundation Plan (1/4″ or 1/2″ = 1′)
  • Floor Plans (1/4″= 1′)
  • Set of Elevations (1/4″= 1′)
  • Miscellaneous Details (3/4″ = 1′)
  • An electrical diagram showing a bird's-eye view of rooms with lights, fans to switches
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
* Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Duplex House Plan with Single Family Appeal

  • 2,110

    Heated s.f.

  • 2

    Units

  • 49' 6"

    Width

  • 54'

    Depth

Floor Plan

  • Main Level

Plan Details

Square Footage Breakdown

  • Total: 2,110 sq. ft.
  • 1st Floor: 2,110 sq. ft.

Dimensions

  • Width: 49' 6"
  • Depth: 54' 0"
  • Max ridge height: 22' 2"

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 4

Foundation Type

    • Standard Foundations: Crawl, Slab

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 8' 0"

Roof

  • Primary Pitch: 8 on 12
  • Framing Type: Stick
