Plan 48587FM Exclusive 4-Bed European Cottage Plan with Split Beds

Exclusive 4-Bed European Cottage Plan with Split Beds

Plan 48587FM

  • 3,236

    Heated s.f.

  • 4

    Beds

  • 3.5

    Baths

  • 1

    Stories

  • 2

    Cars

  • A cathedral ceiling, above the great room, dining room, and foyer, offers a feeling of grandeur immediately upon entering, with a fireplace serving as a focal point. The adjoining kitchen includes a large island with a double-bowl sink, and a nearby walk-in pantry provides ample storage.
  • Natural light floods the breakfast nook through large windows and the adjacent covered patio includes a grill station and a fireplace.
  • To the right of the home, your luxurious master bedroom awaits, which features a sitting area overlooking the backyard and a spacious ensuite with a whirlpool tub, custom tile shower, and a large walk-in closet, complete with an island chest and access to the laundry room.
  • Three additional bedrooms can be found on the opposite side of the home: two share a Jack-and-Jill bath, and the third shares a Jack-and-Jill bathroom with a study.
  • A double garage opens into a mudroom, which neighbors a powder bath, and a separate single garage is perfect for a third car or lawn equipment.

Each plan set includes the following:

Cover Sheet
Floor Plans
Electrical Plan
Foundation Plan
Front and Left Elevation
Rear and Right Elevation
Roof Plan
Cabinets and Section
Building Section


These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required


Floor Plan

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Exclusive 4-Bed European Cottage Plan with Split Beds - 48587FM floor plan - Main Level

Plan details

Exclusive 4-Bed European Cottage Plan with Split Beds

  • 3,236

    Heated s.f.

  • 4

    Beds

  • 4

    Baths

  • 1

    Floors

  • 2

    Car garage

Buy This Plan
  • 5 Sets $1,395
  • 8 Sets $1,535
  • PDF - Single-Build $1,685
  • CAD - Single-Build $2,610
  • View all purchase option online

About This Plan

  • A cathedral ceiling, above the great room, dining room, and foyer, offers a feeling of grandeur immediately upon entering, with a fireplace serving as a focal point. The adjoining kitchen includes a large island with a double-bowl sink, and a nearby walk-in pantry provides ample storage.
  • Natural light floods the breakfast nook through large windows and the adjacent covered patio includes a grill station and a fireplace.
  • To the right of the home, your luxurious master bedroom awaits, which features a sitting area overlooking the backyard and a spacious ensuite with a whirlpool tub, custom tile shower, and a large walk-in closet, complete with an island chest and access to the laundry room.
  • Three additional bedrooms can be found on the opposite side of the home: two share a Jack-and-Jill bath, and the third shares a Jack-and-Jill bathroom with a study.
  • A double garage opens into a mudroom, which neighbors a powder bath, and a separate single garage is perfect for a third car or lawn equipment.

Floor Plans

  • Main Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 3,236 sq. ft.
  • 1st Floor: 3,236 sq. ft.
  • Covered Patio: 356 sq. ft.
  • Porch, Combined: 100 sq. ft.

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 3
  • Half bathrooms: 1

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): 2x4

Dimensions

  • Width: 75' 0"
  • Depth: 84' 0"
  • Max ridge height: 26' 4"

Garage

  • Type: Attached
  • Area: 902 sq. ft.
  • Count: 2 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: First Floor / 10' 0"

Roof

  • Primary Pitch: 6 on 12
  • Secondary Pitch: 8 on 12
