Plan 510200WDY
EXCLUSIVE
Exclusive 4-Bed Home Plan with Formal Dining Area
Heated S.F.
2,254
Beds
4
Baths
3
Stories
1
Cars
2
What's Included
Plan Details
  • Timeless curb appeal defines this exclusive, 4-bedroom home plan, topped by a single dormer window.
  • Dedicated storage space in the 2-car garage is a must have, while just inside, you will find a utility room and full bathroom.
  • In the center of the home, a vaulted ceiling rests above the living room, warmed by a fireplace that can also be enjoyed from the kitchen. A large kitchen island is surrounded by cabinets and counters, and a nearby pantry sits across from a cozy study.
  • Jutting out from the rear of the home, discover the master bedroom, paired with a 5-fixture bathroom and spacious walk-in closet.
  • Three additional bedrooms are dotted throughout the floor plan, each located next to a full bathroom.
What's Included
This house plan set consists of the following elements:

  • Cover Sheet
  • Dimensioned Floor Plans w/ Notes & Details (if more than single level, dimensioned floor plan sheets are included for each level)
  • Exterior Elevations w/ Details
  • Building Section and Roof Plan w/ Trim Details
  • Additional Building Notes and Details
  • Electrical Layout
  • Foundation Plan
  • Foundation Details and Notes

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Exclusive 4-Bed Home Plan with Formal Dining Area

  • 2,254

    Heated s.f.

  • 4

    Beds

  • 3

    Baths

  • 1

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

Plan Details

Square Footage Breakdown

  • Total: 2,254 sq. ft.
  • 1st Floor: 2,254 sq. ft.

Dimensions

  • Width: 54' 9"
  • Depth: 85' 8"
  • Max ridge height: 28' 3"

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 3

Garage

  • Type: Attached
  • Area: 586 sq. ft.
  • Count: 2 Cars
  • Entry Location: Courtyard

Foundation Type

    • Standard Foundations: Slab
    • Optional Foundations: Crawl, Basement

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Roof

  • Primary Pitch: 10 on 12
