Plan 1767LV
Expandable Newport Cottage
Heated S.F.
2,546
Beds
2 - 3
Baths
3.5
Stories
1
Cars
2
Floor Plan

Plan 1767LV

Main Level
slide image 0
Optional Lower Level
slide image 1

Plan 1767LV

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
Optional Lower Level
floor plan image Optional Lower Level
Plan Details
  • Finishing its daylight basement can greatly expand this charming Newport-style cottage. On the main level, you can step out onto a large covered terrace across the back that continues to a screened porch.
  • Vaulted ceilings open up the study and the fireplaced great room, while a tray ceiling tops the master bedroom. Interior columns delineate the great room. The kitchen features a walk-in pantry and an island with a handy vegetable sink.
  • In the secluded master suite, note the walk-in closet and the compartmented bath with its corner garden tub, separate shower and his and her vanities. Completing the main level are a powder room, a laundry room and a guest bedroom with direct access to the full bath.
  • Plans for the basement included with the purchase offer a fireplaced recreation room with a wet bar and access to a large covered terrace. The recreation room opens to a possible exercise room and home theater. Storage space, a full bath and a bedroom with a walk-in closet complete the possibilities for the lower level.
What's Included
  • Dimensioned and detailed Foundation plan (type as listed on home plan description)
  • Dimensioned and detailed floor plans
  • Framing plans
  • Complete front, side and rear elevations
  • Roof plan
  • Typical building sections (as deemed necessary for construction)
  • Typical foundation details, wall sections, and cornice details necessary for construction
  • Separate electrical plan (may be shown on floor plans in some cases)
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.

Square Footage Breakdown

Total Heated Area

2,546 sq. ft.

1st Floor

2,546 sq. ft.

Beds/Baths

Bedrooms

2 or 3

Full bathrooms

3

Half bathrooms

1

Foundation Type

Standard Foundations

Walkout

Exterior Walls

Exterior Walls

2x4

Dimensions

Width

66' 4"

Depth

80' 8"

Max Ridge Height

44' 8"

Garage

Type

Attached

Area

653 sq. ft.

Count

2 Cars

Entry Location

Front

Ceiling Heights

First Floor

10'

Second Floor

9'

Roof Details

Primary Pitch

12 on 12

Framing Type

Stick

Architectural Style

European

Shingle

Special Features

Bedrooms - Clustered

Bonus Room

Butler Walk-in Pantry

Home Theater

Jack & Jill Bath

Laundry - Main Level

Library/Study

Master Suite - 1st Floor

Wet Bar

Square Footage Breakdown

Total Heated Area

2,546 sq. ft.

1st Floor

2,546 sq. ft.

Beds/Baths

Bedrooms

2 or 3

Full bathrooms

3

Half bathrooms

1

Foundation Type

Standard Foundations

Walkout

Exterior Walls

Exterior Walls

2x4

Dimensions

Width

66' 4"

Depth

80' 8"

Max Ridge Height

44' 8"

Garage

Type

Attached

Area

653 sq. ft.

Count

2 Cars

Entry Location

Front

Ceiling Heights

First Floor

10'

Second Floor

9'

Roof Details

Primary Pitch

12 on 12

Framing Type

Stick

Architectural Style

European

Shingle

Special Features

Bedrooms - Clustered

Bonus Room

Butler Walk-in Pantry

Home Theater

Jack & Jill Bath

Laundry - Main Level

Library/Study

Master Suite - 1st Floor

Wet Bar
