Plan 890089AH Gorgeous Craftsman House Plan with Mother-In-Law Suite

Gorgeous Craftsman House Plan with Mother-In-Law Suite

Plan 890089AH

  • 4,206

    Heated s.f.

  • 5

    Beds

  • 4.5

    Baths

  • 2

    Stories

  • 3

    Cars

  • Big and beautiful, this gorgeous Craftsman house plan comes with five bedrooms including a comfortable first floor mother-in-law suite.
  • The open layout gives you sweeping sight lines from room to room so you can better appreciate the vaulted great room that has built-ins on either side of the fireplace.
  • Another cathedral ceiling tops the hearth room that also has a fireplace and built-ins.
  • The master suite occupies the right wing of the home and has a huge walk-in closet that opens directly to the nearby laundry room.
  • Three spacious bedrooms on the upper floor have easy access to the play room for the kids.

Plans include the following:

  • General Notes
  • Rendering
  • Elevations
  • Fully dimensioned floor plans
  • Foundation
  • Typical wall section & stair section
  • Cross section
  • Cabinet elevations
  • Electrical Plan
  • Roof plan

What is NOT included in the plans:

  • Architectural or Engineering Stamp
  • Site Plan
  • Mechanical Drawings (location of heating and air equipment and duct work)
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations)
  • Framing layouts with beam sizes and locations
  • Energy calculations

Floor Plan

Plan details



Gorgeous Craftsman House Plan with Mother-In-Law Suite

  • 4,206

    Heated s.f.

  • 5

    Beds

  • 5

    Baths

  • 2

    Floors

  • 3

    Car garage

Buy This Plan
  • 5 Sets $1,767
  • 8 Sets $1,851
  • PDF - Single-Build $2,313
  • Reproducible Set $2,313
  • CAD - Single-Build $3,701
  • View all purchase option online

About This Plan

  • Big and beautiful, this gorgeous Craftsman house plan comes with five bedrooms including a comfortable first floor mother-in-law suite.
  • The open layout gives you sweeping sight lines from room to room so you can better appreciate the vaulted great room that has built-ins on either side of the fireplace.
  • Another cathedral ceiling tops the hearth room that also has a fireplace and built-ins.
  • The master suite occupies the right wing of the home and has a huge walk-in closet that opens directly to the nearby laundry room.
  • Three spacious bedrooms on the upper floor have easy access to the play room for the kids.

Floor Plans

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total Heated Area: 4,206 sq. ft.
  • 1st Floor: 2,947 sq. ft.
  • 2nd Floor: 1,259 sq. ft.
  • Porch, Combined: 328 sq. ft.

Beds/Baths

  • Bedrooms: 5
  • Full bathrooms: 4
  • Half bathrooms: 1

Foundation Type

    • Standard Foundations: Basement
    • Optional Foundations: Crawl, Slab

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 103' 8"
  • Depth: 68' 4"
  • Max ridge height: 30' 8"

Garage

  • Type: Attached
  • Area: 1097 sq. ft.
  • Count: 3 Cars
  • Entry Location: Side, Front

Ceiling Heights

  • Floor / Height: Lower Level / 9' 0" First Floor / 9' 0" Second Floor / 9' 0"

Roof

  • Primary Pitch: 10 on 12
  • Secondary Pitch: 8 on 12
  • Framing Type: Truss
