Plan 17657LV

Grand Mountain Retreat

Heated S.F.

5,260

Beds

4

Baths

4.5

Stories

2

Cars

3

What's Included

Floor Plan

Main Floor

Reverse Floor Plan

Grand Mountain Retreat - 17657LV floor plan - Main Floor

Second Floor

Reverse Floor Plan

Grand Mountain Retreat - 17657LV floor plan - Second Floor

Lower Level

Reverse Floor Plan

Grand Mountain Retreat - 17657LV floor plan - Lower Level

Plan Details

This magnificent Mountain retreat gives you plenty of space for family and guests.
Shakes, stone and siding plus multiple rooflines add visual interest.
An open concept floor plan can be found in both the formal and informal areas of the home.
The first floor master suite opens to a quiet study with built-ins, a fireplace and a wet bar.
Note the handy pocket office by the kitchen near the walk-in pantry.
Upstairs, a second office and guest bedroom are raised several steps up.
Each bedroom on this level has a private bathroom and walk-in closet.
Should you need more space, a big bonus room over the three car garage awaits your finishing touches.

What's Included

Each plan set includes the following:

Dimensioned and detailed Foundation plan (type as listed on home plan description)
Dimensioned and detailed floor plans
Framing plans
Complete front, side and rear elevations
Roof plan
Typical building sections (as deemed necessary for construction)
Typical foundation details, wall sections, and cornice details necessary for construction
Separate electrical plan (may be shown on floor plans in some cases)

These items are NOT included:

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required

Square Footage Breakdown

Total Heated Area:

5,260 sq. ft.

1st Floor:

3,413 sq. ft.

2nd Floor:

1,847 sq. ft.

Bonus:

679 sq. ft.

Beds/Baths

Bedrooms:

4

Full bathrooms:

4

Half bathrooms:

1

Foundation Type

Standard Foundations:

Crawl

Need A Different Foundation?

Request A Modification Quote

Exterior Walls

Standard Type(s):

2x4

Dimensions

Width:

123' 10"

Depth:

104' 6"

Garage

Type:

Attached

Area:

1147 sq. ft.

Count:

3 Cars

Entry Location:

Courtyard

Ceiling Heights

Floor / Height:

First Floor / 10' 0" Second Floor / 9' 0"

Architectural Style

Special Features

Butler Walk-in Pantry

Laundry - Main Level

Master Suite - 1st Floor

Outdoor Fireplace

Two Story Great Room

Plan Collections
