Interesting Angles

Plan 95005RW

  • 4,936

    Heated s.f.

  • 4

    Beds

  • 4.5

    Baths

  • 1

    Stories

  • 3

    Cars

  • This Mountain home plan has a terrific curb appeal due to its interesting angles that flare out to the sides.
  • Special features throughout the home will delight the homeowners, such as beamed vaulted ceilings in the great room, a vaulted covered rear deck, beautiful master suite and a knock-out lower level.
  • Party up in the lower level rec room with a wet bar or relax with your favorite book in the lower library.
  • Designed with a large craft room, this could also serve as an extra bedroom with walk-in closet.
  • Even the three car garage is large with extra space for storage.

  • Cover Page
  • 4 elevations
  • Floorplans
  • Foundation plan (with no specifications of structural elements)
  • Roof plan (with no specifications of structural elements)
  • Typical wall sections
  • Electrical plan
The following details are NOT included in the plans:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • REScheck or other energy related calculations are NOT included.
  • Wind load or seismic calculations are NOT included.
  • Framing plans or beam sizes are NOT included.
  • Other specific drawings that your local permit office may requires

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Interesting Angles - 95005RW floor plan - Main Level

Lower Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Interesting Angles - 95005RW floor plan - Lower Level

Plan details

Square Footage Breakdown

  • Total Heated Area: 4,936 sq. ft.
  • Lower Level: 2,040 sq. ft.
  • 1st Floor: 2,896 sq. ft.

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 4
  • Half bathrooms: 1

Foundation Type

  • Standard Foundations: Basement, Walkout

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 94' 0"
  • Depth: 85' 0"
  • Max ridge height: 27' 6"

Garage

  • Type: Attached
  • Area: 1461 sq. ft.
  • Count: 3 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: Lower Level / 10' 0" First Floor / 9' 0"

Roof Details

  • Primary Pitch: 8 on 12
  • Framing Type: Truss

Architectural Style

Special features

Plan Collections

Interesting Angles

  • 4,936

    Heated s.f.

  • 4

    Beds

  • 4.5

    Baths

  • 1

    Floors

  • 3

    Car garage

Buy This Plan
  • PDF - Single-Build $3,750
  • CAD - Single-Build $5,450
  • View all purchase option online

About This Plan

  • This Mountain home plan has a terrific curb appeal due to its interesting angles that flare out to the sides.
  • Special features throughout the home will delight the homeowners, such as beamed vaulted ceilings in the great room, a vaulted covered rear deck, beautiful master suite and a knock-out lower level.
  • Party up in the lower level rec room with a wet bar or relax with your favorite book in the lower library.
  • Designed with a large craft room, this could also serve as an extra bedroom with walk-in closet.
  • Even the three car garage is large with extra space for storage.
