Plan 62401DJ Mediterranean-Style 3-Car Detached Garage Plan

Mediterranean-Style 3-Car Detached Garage Plan

Plan 62401DJ

Each plan set includes:

  • Cover Sheet: Shows the front elevation and typical notes and requirements.
  • Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurement
  • Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor
  • Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
  • Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
  • Roof Plan
  • Typical wall section
  • Typical Stair section
  • Cabinets are shown on most but not all plans. If cabinets are a must please call to confirm they will be included in your set.

Floor Plan

Plan details

Special features


Mediterranean-Style 3-Car Detached Garage Plan

  • 0

    Heated s.f.

  • 0


  • 0


  • 1


  • 3

    Car garage

Buy This Plan
  • PDF - Single-Build $449
  • CAD - Single-Build $699
  • 5 Sets + PDF $949
  • PDF - Unlimited Build $949
  • CAD - Unlimited Build $1,199
  • View all purchase option online

About This Plan

Floor Plans

  • Main Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 0 sq. ft.


  • Bedrooms: 0

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6


  • Width: 36' 0"
  • Depth: 26' 0"
  • Max ridge height: 15' 10"


  • Type: Detached
  • Area: 888 sq. ft.
  • Count: 3 Cars

Ceiling Heights

  • Floor / Height: First Floor / 10' 0"


  • Primary Pitch: 6 on 12
  • Framing Type: Stick
