Modern Farmhouse House Plan with 3 Beds, Split Layout, and Open Living

Name: Plan 54053LK: Modern Farmhouse House Plan with 3 Beds, Split Layout, and Open Living
Brand: Architectural Designs
SKU: 54053LK
Price: 1441.39 USD
Availability: InStock

Heated S.F.

2,248

Beds

Baths

Stories

Cars

Floor Plan

Main Level

Plan Details

This 2,248 sq ft Modern Farmhouse House Plan features 3 bedrooms, 2 full baths, and an attached 721 sq ft 2-car garage.
A welcoming front porch leads into a high-ceiling foyer, opening directly to the expansive, open-concept great room with a sloped ceiling and abundant natural light.
The heart of the home features a seamless flow between the great room, casual dining area, and a well-appointed kitchen with an island and walk-in pantry.
The private master suite, complete with a sitting area and a luxurious master bath with dual closets, is thoughtfully separated from two secondary bedrooms which share a full bath.
Enjoy outdoor living on the generous 546 sq ft combined porches, including a spacious covered porch ideal for relaxation or entertaining.

What's Included

FLOOR PLAN: Showing all dimensions, window & door locations, laminated beams, columns, floor materials, ceiling heights, fireplace size, window & door schedules and specifications
FOUNDATION PLAN: Dimensioned plan detailing the location and size of footings, slabs, brick shelves reinforcing steel, direction and size of ceiling joists, Laminate beam locations, specifications covering soil pressure, concrete strength, and requirements for the contractor to follow accepted practices.
ELECTRICAL PLAN: Specifications, notes, schedules, and plan defining the location of panels, service, lighting fixtures, switches and outlets.
ELEVATIONS: The front, rear and side elevations of the house as drawn. Shows placement of doors & windows on exterior of house, as well as roof pitches, and locations of chimney, exterior vents, etc. and also includes any necessary details.
ROOF PLANS: Provides a bird's eye view of the roof's valleys, ridges and dormers, if applicable
BUILDING CROSS SECTION: Shows details of the house as though it were cut in slices from the roof to the foundation. The cross sections detail the construction of the home, insulation, flooring and roofing.
INTERIOR ELEVATIONS: Show's how the details of cabinets such as those found in the kitchen, bathroom and utility room, fireplaces and other special interior features.
NOTES AND DETAILS: Provides information for structural specifications, excavating and grading, masonry and concrete work, carpentry and wood specifications, thermal and moisture protection and specifications about drywall, tile, flooring, glazing, caulking and sealants.

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
