Plan 12917KN

Private Guest Suite

Heated S.F.

2,835

Beds

3

Baths

3.5

Stories

1

Cars

2

What's Included

Floor Plan

Main Level

Reverse Floor Plan

Private Guest Suite - 12917KN floor plan - Main Level

2nd Floor

Reverse Floor Plan

Private Guest Suite - 12917KN floor plan - 2nd Floor

Plan Details

Unusual clipped rooflines enhance this Mountain home plan.
Spires and metal roofing over the porches are added touches.
A spacious dining room lies right off the foyer as you enter the home.
The kitchen is huge with a center island that gives you more counter space.
Off to the right is the giant family room with folding doors that open the room to the rear patio.
A secluded master suite is set off by itself where you can relax at the end of the day.
A second bedroom is on this level and a private guest bedroom occupies the second floor all by itself.

What's Included

Floor plans at ¼" scale
All exterior elevations at ¼" scale
Roof plan at ¼" scale
Building sections at ¼" scale
Completed foundation plan at ¼" scale
Completed floor/roof framing plan at ¼" scale
Building height profiles at ¼" scale
Door and window schedules
General construction notes and building schedules
Exterior finish schedule
Architectural details
Construction details for cabinets, interior built-ins and stairs
Designations for all floor, wall and ceiling surfaces
Details and specifications for all ceiling treatments
All square footage calculations

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required

Square Footage Breakdown

Total Heated Area:

2,835 sq. ft.

1st Floor:

2,493 sq. ft.

2nd Floor:

342 sq. ft.

Beds/Baths

Bedrooms:

3

Full bathrooms:

3

Half bathrooms:

1

Foundation Type

Standard Foundations:

Crawl, Slab

Need A Different Foundation?

Request A Modification Quote

Exterior Walls

Standard Type(s):

2x6

Dimensions

Width:

61' 0"

Depth:

88' 0"

Garage

Type:

Attached

Area:

577 sq. ft.

Count:

2 Cars

Entry Location:

Courtyard

Ceiling Heights

Floor / Height:

First Floor / 9' 0" Second Floor / 8' 0"

Architectural Style

Special Features

Bedrooms - Clustered

Butler Walk-in Pantry

Laundry - Main Level

Master Suite - 1st Floor
