Plan 59330ND
Southern Traditional Duplex House Plan with Matching 1750 Square Foot Units
Heated S.F.
3,500
Units
2
Width
78'
Depth
73' 8"
Cars
4
Plan Details
  • Each one-story unit in this southern traditional-style duplex house plan gives you 1,750 square feet of heated living space and a 2-car 400 square foot garage.
  • Bedrooms line the outside walls and the gathering spaces are in the interior parts of each unit.
Unit A
1,750 Sq. Ft.
1750 Sq. Ft. 1st Floor
3 Beds
2 Full Baths
2 Vehicle
Attached
400 Sq. Ft.
39' w 73' 8" d 28' h
Unit B
1,750 Sq. Ft.
1750 Sq. Ft. 1st Floor
3 Beds
2 Full Baths
2 Vehicle
Attached
400 Sq. Ft.
39' w 73' 8" d 28' h
What's Included
  • Foundation Plan** (1/4″ or 1/2″ = 1′)
  • Floor Plans (1/4″= 1′)
  • Set of Elevations (1/4″= 1′)
  • Miscellaneous Details (3/4″ = 1′)
  • An electrical diagram showing a birdseye view of rooms with lights, fans to switches
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
* Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Southern Traditional Duplex House Plan with Matching 1750 Square Foot Units

  • 3,500

    Heated s.f.

  • 2

    Units

  • 78'

    Width

  • 73' 8"

    Depth

Floor Plan

  • Main Level

Plan Details

Square Footage Breakdown

  • Total: 3,500 sq. ft.
  • 1st Floor: 3,500 sq. ft.

Dimensions

  • Width: 78' 0"
  • Depth: 73' 8"
  • Max ridge height: 28' 0"

Beds/Baths

  • Bedrooms: 6
  • Full bathrooms: 4

Garage

  • Type: Attached
  • Area: 800 sq. ft.
  • Count: 4 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Slab, Crawl

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof

  • Primary Pitch: 12 on 12
  • Framing Type: Stick
