Split Bedroom Layout

Plan 59651ND

  • 1,689

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Stories

  • 2

    Cars

  • A stylish hip roof and covered front porch grace this Southern house plan.
  • You'll have lots of room to spread out in the enormous vaulted living room with its fireplace.
  • Sliding glass doors in the dining area lead out to a rear covered grilling porch.
  • The U-shaped kitchen is a model of efficiency and has views of the porch from the kitchen sink.
  • Split bedrooms give the master suite a defined space away from the other bedrooms.
  • Each of the secondary bedrooms has a walk-in closet and bedroom 2 gets a built-in desk.

Each plan set includes the following:

  • Foundation Plan** (1/4″ or 1/2″ = 1′)
  • Floor Plans (1/4″= 1′)
  • Set of Elevations (1/4″= 1′)
  • Building Sections (1/4″ or 1/2″ = 1′)
  • Kitchen and Bath Elevations (1/2″ = 1′)
  • Miscellaneous Details (3/4″ = 1′)
  • An electrical diagram showing a Birdseye view of rooms with lights, fans to switches

Floor Plan

Plan details

Architectural Style



Split Bedroom Layout

  • 1,689

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Floors

  • 2

    Car garage

Buy This Plan
  • PDF - single-use $800
  • 5 Sets $900
  • CAD $1,600
  • View all purchase option online

About This Plan

  • A stylish hip roof and covered front porch grace this Southern house plan.
  • You'll have lots of room to spread out in the enormous vaulted living room with its fireplace.
  • Sliding glass doors in the dining area lead out to a rear covered grilling porch.
  • The U-shaped kitchen is a model of efficiency and has views of the porch from the kitchen sink.
  • Split bedrooms give the master suite a defined space away from the other bedrooms.
  • Each of the secondary bedrooms has a walk-in closet and bedroom 2 gets a built-in desk.

Floor Plans

  • Main Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 1,689 sq. ft.
  • 1st Floor: 1,689 sq. ft.
  • Porch, Combined: 351 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2

Foundation Type

    • Standard Foundations: Crawl, Slab
    • Optional Foundations: Basement, Walkout

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 59' 0"
  • Depth: 69' 0"
  • Max ridge height: 22' 0"

Garage

  • Type: Attached
  • Area: 537 sq. ft.
  • Count: 2 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof

  • Primary Pitch: 9 on 12
  • Framing Type: Stick
