Plan 86284HH
Stately Southern House Plan
Heated S.F.
2,905
Beds
4-5
Baths
3
Stories
1
Cars
2
What's Included
Plan Details
  • There's a lot of space in this stately Southern house plan that comes with a side-load drive-under garage.
  • Four of the bedrooms are on the main floor but the lower level has a very private bedrooms suite with a walk-in closet and a three-quarter bathroom that would make an excellent in-law suite.
  • The main living space is in the center of the home with an open layout that joins the vaulted great room with the breakfast nook and kitchen.
  • A 42" high peninsula eating counter seats five people.
  • Use bedroom 4 as a study if desired.
  • The master suite has the whole left side of the home with a large soaking tub in the master bathroom and a big walk-in closet.
  • Add a deck in back as space permits on your lot.
What's Included
  • Cover Sheet
  • Foundation plans
  • Elevations - complete with dimensions, ridge heights and special notes
  • Floor Plans - complete with dimensions of all elements including plumbing, appliances and cabinet sizes
  • Roof Plan - complete with dimensions, plate heights, roof pitches and notes for special conditions
  • Rafter Plan
  • Details
  • Interior Elevations - include applicable cabinetry, electrical and special construction notes
  • Floor Joist Plan - complete with spans, sizes and direction (if applicable)
  • Ceiling Joist - complete with spans, sizes and direction
  • Sections - complete with dimensions, notes and specifications
  • Electrical plan - complete wit layout, light fixtures, outlets and legend
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
