Stately Two Car Garage

Plan 92049VS

  • 0

    Heated s.f.

  • 0

    Beds

  • 1-2

    Stories

  • 2

    Cars

  • This two car garage has a stately look to it with the high roof pitch allowing for a large room above.
  • Exterior stairs allow for access to what could be a home office or detached recreational room.
  • The garage doors measure 9' x 7'.

All plans include:

  • Foundation plan
  • Floor plans with electrical layouts
  • 1/4" Elevations (all sides)
  • Cabinet details and interior elevations (when necessary)
  • Roof Plan
  • Typical Wall Section and two standard detail sheets
  • General Notes Page containing reference to the 2012 IRC building code to supplement plans drawn prior to these changes.
  • Other details shown as required by complexity of plans


These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Stately Two Car Garage - 92049VS floor plan - Main Level
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Stately Two Car Garage - 92049VS floor plan - Bonus

Special features

Plan Collections

Stately Two Car Garage

  • 0

    Heated s.f.

  • 0

    Beds

  • 0

    Baths

  • 1-2

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

  • Bonus

Plan Details

Square Footage Breakdown

  • Total: 0 sq. ft.

Dimensions

  • Width: 24' 0"
  • Depth: 26' 0"
  • Max ridge height: 21' 4"

Beds/Baths

  • Bedrooms: 0

Garage

  • Type: Detached
  • Area: 624 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 8' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 12 on 12
  • Secondary Pitch: 3.5 on 12
  • Framing Type: Stick
