Plan 890111AH

Traditional Craftsman House Plan with Split Beds

Heated S.F.

2,510

Beds

3

Baths

2.5

Stories

1

Cars

3

What's Included

Floor Plan

Main Level

Reverse Floor Plan

Traditional Craftsman House Plan with Split Beds - 890111AH floor plan - Main Level

Plan Details

This traditional, craftsman home design is sure to stand out in the sea of ranch homes in today’s world.
A soaring entry welcomes you as you head inside, where you'll immediately find views through the great room to the backyard.
A generous kitchen features a center island, overlooking the great room.
To the side of the kitchen, you'll find the dining room, with a den off the left, and the back deck is perfect for a grilling station.
Past a computer nook, discover the master suite, which includes two walk-in closets, and a spacious bath.
The other two bedrooms share a Jack-and-Jill bath on the opposite side of the home.
Completing this design is a three-stall side load garage.
Restricted: This plan cannot be built with 30 miles of Milwaukee, Wisconsin.

What's Included

General Notes
Rendering
Elevations
Fully dimensioned floor plans
Foundation
Typical wall section & stair section
Cross section
Cabinet elevations
Electrical Plan
Roof plan

What's Not Included

Architectural or Engineering Stamp
Site Plan
Mechanical Drawings (location of heating and air equipment and duct work)
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations)
Framing layouts with beam sizes and locations
Energy calculations

Square Footage Breakdown

Total Heated Area:

2,510 sq. ft.

1st Floor:

2,510 sq. ft.

Porch, Combined:

116 sq. ft.

Beds/Baths

Bedrooms:

3

Full bathrooms:

2

Half bathrooms:

1

Foundation Type

Standard Foundations:

Basement

Optional Foundations:

Slab, Crawl

Need A Different Foundation?

Request A Modification Quote

Exterior Walls

Standard Type(s):

2x6

Dimensions

Width:

70' 6"

Depth:

78' 0"

Max Ridge Height:

27' 10"

Garage

Type:

Attached

Area:

794 sq. ft.

Count:

3 Cars

Entry Location:

Courtyard

Ceiling Heights

Lower Level

8'

First Floor

9'

Roof Details

Primary Pitch:

10 on 12

Secondary Pitch:

12 on 12

Framing Type:

Truss

Architectural Style

Special Features

Bedrooms - Split

Butler Walk-in Pantry

Jack & Jill Bath

Master Suite - 1st Floor

Plan Collections
