Plan 59678ND
Traditional House Plan with Future Game Room
Heated S.F.
2,703
Beds
3
Baths
2.5
Stories
2
Cars
3
What's Included
Plan Details
  • Open and airy, this Traditional house plan comes with an extra: a reinforced walk-in storm closet in the master suite where you can shelter in a storm.
  • Two handsome box columns serve to define the foyer while keeping the views open.
  • The vaulted formal dining room soars up two stories and is visible from the open rail staircase going up.
  • Five people can sit comfortably at the peninsula eating bar and chat with the family chef while cooking.
  • In back, open decks and covered porches give you marvelous outdoor space.
  • Each bedroom on the second floor has a charming dormer window and a walk-in closet.
  • The proposed game room comes with options for built-in bunk beds and a window seat.
What's Included
  • Foundation Plan** (1/4″ or 1/2″ = 1′)
  • Floor Plans (1/4″= 1′)
  • Set of Elevations (1/4″= 1′)
  • Miscellaneous Details (3/4″ = 1′)
  • An electrical diagram showing a birdseye view of rooms with lights, fans to switches
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Traditional House Plan with Future Game Room

  • 2,703

    Heated s.f.

  • 3

    Beds

  • 2.5

    Baths

  • 2

    Floors

  • 3

    Car garage

Floor Plan

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 2,703 sq. ft.
  • 1st Floor: 2,132 sq. ft.
  • 2nd Floor: 571 sq. ft.

Dimensions

  • Width: 90' 4"
  • Depth: 48' 9"
  • Max ridge height: 25' 10"

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2
  • Half bathrooms: 1

Garage

  • Type: Carport
  • Area: 691 sq. ft.
  • Count: 3 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Crawl, Slab
    • Optional Foundations: Basement, Walkout

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 9' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 10 on 12
  • Secondary Pitch: 3.5 on 12
  • Framing Type: Stick
All house plans are copyright ©2024 by the architects and designers represented on our web site
