Two-Story New American House Plan with First-Floor Master Suite

Pageloader

Two-Story New American House Plan with First-Floor Master Suite

Plan 710260BTZ

  • 2,848

    Heated s.f.

  • 4

    Beds

  • 2.5

    Baths

  • 2

    Stories

  • 2

    Cars

  • Timber-frame gables and stone accents contribute to the great curb appeal offered by this two-story, New American house plan.
  • Inside, two fireplaces add warmth to the light and airy, shared living spaces on the main level.
  • The kitchen features a wrap-around island, adjacent to the keeping room and breakfast nook, and a pantry sits within reach for easy access.
  • Retreat to the well-appointed, master suite, which boasts a tray ceiling, sitting area in the bay window, and vaulted ceiling in the en suite, complete with a large walk-in closet.
  • Upstairs, three additional bedrooms share a compartmentalized, full bath, and a spacious family center offers a fun space for the kids to enjoy.
  • Related Plan: Get an alternate exterior with house plan 710291BTZ.

The plans include the following:

  • Elevations -  at 1/4" or 3/16" and the side and rear elevations at 1/8" scale. The elevations show and note the exterior finished materials of the house.
  • Foundation - every plan is available with a walkout style basement (three masonry walls and one wood framed rear wall with windows and doors).  The basement plans are a 1/4" or 3/16" scale layout of unfinished spaces showing only the necessary 2 x 6 wood framed load bearing walls.  These plans are completed with dimensions, door/window sizes.  Crawlspace and/or slab on grade foundations are available for some plans.
  • Floor plan - each plan consists of 1/4" or 3/16" scale layouts showing the location of 2 x 4 walls, doors, windows, plumbing fixtures, cabinetry, stairs and decorative ceilings. These plans are complete with dimensions, notes, door/window sizes and a schematic electrical layout.
  • Building sections - Take vertical cuts throughout the house and the stairs showing floor, ceiling and roof height information.
  • Kitchen & Bath elevations - show the arrangement and size of each cabinet and other fixtures in the room.
  • Floor framing - if included it shows each floor joist indicating the size, spacing and length.  All beams are sized and labeled.  Each framing plan sheet includes any framing details that are needed (tray details, connections details, etc. All framing is designed using conventional 2 x 10 floor joist or wood I-joist, depending on the span conditions of each home. FRAMING PLANS ARE NOT AVAILABLE for all home so please follow up with us for availability.
  • Ceiling framing - if included, it shows each ceiling joist indicating the size, spacing and length.  All beams are sized and labeled.  All of the joists are counted and coordinated with the material list.  FRAMING PLANS ARE NOT AVAILABLE for all home so please follow up with us for availability.
  • Roof framing - if included, shows each rafter, valley, hip and ridge indicating size, spacing and length.  All beams are sized and labeled.  All of the joists are counted and coordinated with the material list.  FRAMING PLANS ARE NOT AVAILABLE for all home so please follow up with us for availability.
  • Details sheets - shows foundation details, typical wall section and other framing details.  Also included are miscellaneous interior trim and fireplace details that can be used to customize the home.


Floor Plan

Plan details



Two-Story New American House Plan with First-Floor Master Suite

  • 2,848

    Heated s.f.

  • 4

    Beds

  • 3

    Baths

  • 2

    Floors

  • 2

    Car garage

Buy This Plan
  • 5 Sets $1,280
  • 8 Sets $1,380
  • PDF - multi-use $1,490
  • Reproducible Set $1,565
  • CAD - multi-use $2,850
  • View all purchase option online

About This Plan

  • Timber-frame gables and stone accents contribute to the great curb appeal offered by this two-story, New American house plan.
  • Inside, two fireplaces add warmth to the light and airy, shared living spaces on the main level.
  • The kitchen features a wrap-around island, adjacent to the keeping room and breakfast nook, and a pantry sits within reach for easy access.
  • Retreat to the well-appointed, master suite, which boasts a tray ceiling, sitting area in the bay window, and vaulted ceiling in the en suite, complete with a large walk-in closet.
  • Upstairs, three additional bedrooms share a compartmentalized, full bath, and a spacious family center offers a fun space for the kids to enjoy.
  • Related Plan: Get an alternate exterior with house plan 710291BTZ.

Floor Plans

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total Heated Area: 2,848 sq. ft.
  • 1st Floor: 1,780 sq. ft.
  • 2nd Floor: 1,068 sq. ft.
  • Basement Unfinished: 1,780 sq. ft.

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 2
  • Half bathrooms: 1

Foundation Type

    • Standard Foundations: Basement, Crawl

Exterior Walls

  • Standard Type(s): 2x4

Dimensions

  • Width: 60' 4"
  • Depth: 47' 6"
  • Max ridge height: 28' 0"

Garage

  • Type: Attached
  • Area: 458 sq. ft.
  • Count: 2 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: First Floor / 9' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 10 on 12
  • Framing Type: Stick
