Plan 57214HA

Ultimate Guy's Retreat

Heated S.F.
1,170
Beds
0
Baths
1
Stories
2
Cars
2

Floor Plan

Plan 57214HA

Main Level
Main Level
Second Level
Second Level

Plan 57214HA

M-F 9am-5pm EST |

1-203-761-8500

Main Level

Plan 57214HA: Ultimate Guy's Retreat - Floor Plan - Main Level - Carriage, Traditional

Second Level

Plan 57214HA: Ultimate Guy's Retreat - Floor Plan - Second Level - Carriage, Traditional

Plan Details

  • This unassuming garage disguises the ultimate guy's retreat.
  • Upstairs, the rear wall is designed to hold your home theater (up to 10' wide). A corner bar with kitchen and a full bath mean you don't have to go far for any creature comforts.
  • A fireplace and a tray ceiling are nice touches.
  • On the ground level, the garage features two 10'x7' overhead doors. The shop with bench and an office add more uses to this unique structure.
  • Related Plan: Get a rear-entry garage with plan 57215HA.

What's Included

  • Front Cover Sheet
  • Detailed Floor Plans
  • Foundation Plan
  • Roof Plan
  • Exterior Elevations
  • Interior Elevations
  • Cross Section
  • Mechanical – Shows location of furnace
  • Electrical – Shows location of outlets, switches and fixtures
  • Plumbing – Shows location of fixtures

What's Not Included

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Starting at

Ready to Get Started?

Select your plan set options before checkout.

Price Match Guarantee
What's included?

Modify this Plan

Receive a free modification quote within 3 business days.

Start with a Cost Report

Calculate the cost to build & furnish your home.

Square Footage Breakdown

Total Heated Area

1,170 sq. ft.

1st Floor
