3-Bed Barndominium with Wraparound Porch and 41' by 53' Shop
Heated S.F.
3,754
Beds
3
Baths
2.5
Stories
2
Cars
4
What's Included
Plan Details
  • Front and rear porches surround the 3,754 square feet of living space in this 3-bedroom Barndominium home plan, while the oversized garage measuring 41' by 53' delivers pass-thru capabilities with two 12' by 14' overhead doors.
  • The front door takes you directly into the heart of the home with an island kitchen framed by a dining area and two-story great room.
  • Retreat to the master bedroom and find a walk-in closet, safe room, and a steam room in the ensuite.
  • The laundry room is conveniently located near the kitchen and doubles as a mudroom with a built-in bench and lockers.
  • Two similarly-sized bedrooms are separated by a full bathroom and a spacious loft upstairs offers a multi-purpose space for all to enjoy.
What's Included
  • Elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
