Plan 510118WDY 3-Bed European Home Plan with Split Bedrooms

3-Bed European Home Plan with Split Bedrooms

Plan 510118WDY

  • 2,059

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Stories

  • 2

    Cars

  • The lighter-toned brick provides this 3-bedroom, European home plan with loads of old-world charm, while the interior is designed to offer modern comforts to today's family.
  • The living room opens to the kitchen in the center of the home, bordered by a front and rear porch for maximum outdoor enjoyment. An oversized, kitchen island anchors the living space, and a nearby pantry lends plenty of dry storage space.
  • The master bedroom occupies the right side of the home, and includes the standard amenities in a 5-fixture bath. A pocket office sits just outside the master.
  • Bedrooms 2 and 3 are located on the opposite side of the home, and share a full bath.
  • The 2-car garage includes a storage nook to keep clutter at bay, and opens into a mudroom with built-in cubbies.

This house plan set consists of the following elements:


  • Cover Sheet
  • Dimensioned Floor Plans w/ Notes & Details (if more than single level, dimensioned floor plan sheets are included for each level)
  • Exterior Elevations w/ Details
  • Building Section and Roof Plan w/ Trim Details
  • Additional Building Notes and Details
  • Electrical Layout
  • Foundation Plan
  • Foundation Details and Notes

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
3-Bed European Home Plan with Split Bedrooms - 510118WDY floor plan - Main Level

Plan details

3-Bed European Home Plan with Split Bedrooms

  • 2,059

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Floors

  • 2

    Car garage

Buy This Plan
  • 5 Sets $600
  • PDF - Unlimited Build $1,000
  • 5 Sets + PDF $1,250
  • CAD - Unlimited Build $1,544
  • View all purchase option online

About This Plan

  • The lighter-toned brick provides this 3-bedroom, European home plan with loads of old-world charm, while the interior is designed to offer modern comforts to today's family.
  • The living room opens to the kitchen in the center of the home, bordered by a front and rear porch for maximum outdoor enjoyment. An oversized, kitchen island anchors the living space, and a nearby pantry lends plenty of dry storage space.
  • The master bedroom occupies the right side of the home, and includes the standard amenities in a 5-fixture bath. A pocket office sits just outside the master.
  • Bedrooms 2 and 3 are located on the opposite side of the home, and share a full bath.
  • The 2-car garage includes a storage nook to keep clutter at bay, and opens into a mudroom with built-in cubbies.

Floor Plans

  • Main Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 2,059 sq. ft.
  • 1st Floor: 2,059 sq. ft.
  • Porch, Combined: 285 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2

Foundation Type

    • Standard Foundations: Slab
    • Optional Foundations: Crawl, Basement

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 59' 10"
  • Depth: 81' 8"

Garage

  • Type: Attached
  • Area: 560 sq. ft.
  • Count: 2 Cars
  • Entry Location: Courtyard

Ceiling Heights

  • Floor / Height: First Floor / 10' 0"

Roof

  • Primary Pitch: 12 on 12
  • Framing Type: Stick
