3 Bed French Acadian House Plan

Pageloader

3 Bed French Acadian House Plan

Plan 56327SM

  • 2,231

    Heated s.f.

  • 3

    Beds

  • 2.5

    Baths

  • 1

    Stories

  • 2

    Cars

  • This house plan features a great French Acadian style look with a split floorplan making this a great home for entertaining.
  • Ample windows in the back give you great views to the rear yard.
  • The living room features a fireplace and provides separation from the master wing and the family bedrooms.
  • The master bedroom has a 10' tray ceiling and has direct access to the rear porch.
  • All the bedrooms have walk-in closets.
  • The 2 car side entry garage is great for corner lots and has a 232 square foot storage area.
  • The main roof pitch is 9:12.

Each plan set includes the following:

  • FLOOR PLAN: Showing all dimensions, window & door locations, laminated beams, columns, floor materials, ceiling heights, fireplace size, window & door schedules and specifications
  • DOOR, WINDOW AND ROOF FINISH SCHEDULES: Window & Door schedules as well as room finish schedules showing flooring specs, crown molding, cabinets, countertop materials, & ceiling heights.
  • FOUNDATION PLAN AND CEILING JOISTS LAYOUT: Dimensioned plan detailing the location and size of footings, slabs, brick shelves reinforcing steel, direction and size of ceiling joists, Laminate beam locations, specifications covering soil pressure, concrete strength, and requirements for the contractor to follow accepted practices.
  • ELECTRICAL PLAN: Specifications, notes, schedules, and plan defining the location of panels, service, lighting fixtures, switches, outlets, smoke detectors, cable TV and telephones.
  • HVAC / MECHANICAL PLAN: Specifications, notes, air handler details and plans showing the locations and size of HVAC units, compressors, vents, grills, cfm flows, attic access and clearances.
  • FRONT AND REAR ELEVATIONS: The front and rear elevation of the house as drawn. Shows placement of doors & windows on exterior of house, as well as roof pitches, and locations of chimney, exterior vents, etc. and also includes any necessary details.
  • SIDE ELEVATIONS, ROOF PLANS, WALL SECTIONS AND FRAMING DETAILS: Side views of house, and necessary framing and roofing details. Also included are wall sections, and any other necessary details for your framer or other subcontractors.

Floor Plan

Plan details



3 Bed French Acadian House Plan

  • 2,231

    Heated s.f.

  • 3

    Beds

  • 3

    Baths

  • 1

    Floors

  • 2

    Car garage

Buy This Plan
  • PDF - single-use $900
  • 6 Sets $1,000
  • 5 Sets PLUS $1,200
  • CAD $1,900
  • CAD - multi-use $2,295
  • View all purchase option online

About This Plan

  • This house plan features a great French Acadian style look with a split floorplan making this a great home for entertaining.
  • Ample windows in the back give you great views to the rear yard.
  • The living room features a fireplace and provides separation from the master wing and the family bedrooms.
  • The master bedroom has a 10' tray ceiling and has direct access to the rear porch.
  • All the bedrooms have walk-in closets.
  • The 2 car side entry garage is great for corner lots and has a 232 square foot storage area.
  • The main roof pitch is 9:12.

Floor Plans

  • Main Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 2,231 sq. ft.
  • 1st Floor: 2,231 sq. ft.
  • Porch, Combined: 519 sq. ft.
  • Storage: 242 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2
  • Half bathrooms: 1

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): 2x4

Dimensions

  • Width: 70' 10"
  • Depth: 82' 3"
  • Max ridge height: 26' 8"

Garage

  • Type: Attached
  • Area: 528 sq. ft.
  • Count: 2 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof

  • Primary Pitch: 9 on 12
