Plan 420047WNT 3-Bed Modern Mountain Home Plan with Stacked Stone Fireplace

3-Bed Modern Mountain Home Plan with Stacked Stone Fireplace

Plan 420047WNT

  • 1,364

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Stories

  • This home gives you 1,364 square feet of heated living space with 3 bedrooms and 2 baths with a mixed material exterior. A vaulted front porch with deep eaves gives you a great fresh air space.
  • The defining feature of this 3-bed modern mountain home plan is the stacked stone fireplace centered on a wall of glass in the vaulted living room.
  • A C-shaped kitchen gives you counter seating and views across the living room and out the front. The sink is centered below a window looking out the side.
  • A pocket door closes off the mud room which gives you storage and a place for side-by-side washer and dryer.
  • The bedrooms are clustered on the right side of the home. The master suite has access to a private porch through sliding doors, a walk-in closet and a bathroom with two vanities. The other bedrooms share a bathroom.

What is Included in Our Plans?

Each plan is designed to meet nationally recognized building codes for the year they were created. Following is a listing of sheets included in our plans:

Foundation Plan

outlines details of the slab, crawl space, or basement specifically associated with the house that this plan has been designed for. These details may include; Footing sizes and locations, Floor framing information, Slab information etc.

Floor Plan

shows the placement of interior walls and the dimensions for rooms, doors, windows, stairways, etc. of each level of the house.

Exterior Elevations

show the front, rear and sides of the house, including exterior materials, details and roof pitches.

Building Cross Section

shows details of the house as though it were cut in slices from the roof to the foundation. The cross sections detail the construction of the home, insulation, flooring and roofing.


Roof Plan

provides a bird's eye view of the roof's valleys, ridges and dormers, if applicable

Electrical Plan (when available)

shows the suggested locations for fixtures and outlets. Please contact us to see if an electrical plan is included in the plan set.

Notes & Details

provides information for structural specifications, excavating and grading, masonry and concrete work, carpentry and wood specifications, thermal and moisture protection and specifications about drywall, tile, flooring, glazing, caulking and sealants.

What is not included in the plans:

  •           Architectural or Engineering Stamp
  •           Site Plan (available as an upgrade option)
  •           Mechanical Drawings (location of heating and air equipment and duct work)
  •           Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations)
  •           Framing layouts with beam sizes and locations
  •           Energy calculations

Building Code

Because of the wide range of requirements throughout states and municipalities, it is possible that the plans may not have all of the information required by your building department. If this is the case, we recommend hiring a local design professional or engineer who can assist bringing the plans up to your local building code.

Engineering

Some states require that a licensed architect or engineer review and stamp the plans. If this is the case where you will be building, a local professional will be able to assist you.

Floor Plan

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
3-Bed Modern Mountain Home Plan with Stacked Stone Fireplace - 420047WNT floor plan - Main Level

Plan details

3-Bed Modern Mountain Home Plan with Stacked Stone Fireplace

  • 1,364

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Floors

Buy This Plan
  • PDF - Single-Build $995
  • 5 Sets $1,145
  • 5 Sets + PDF $1,245
  • CAD - Unlimited Build $1,895
  • View all purchase option online

About This Plan

  • This home gives you 1,364 square feet of heated living space with 3 bedrooms and 2 baths with a mixed material exterior. A vaulted front porch with deep eaves gives you a great fresh air space.
  • The defining feature of this 3-bed modern mountain home plan is the stacked stone fireplace centered on a wall of glass in the vaulted living room.
  • A C-shaped kitchen gives you counter seating and views across the living room and out the front. The sink is centered below a window looking out the side.
  • A pocket door closes off the mud room which gives you storage and a place for side-by-side washer and dryer.
  • The bedrooms are clustered on the right side of the home. The master suite has access to a private porch through sliding doors, a walk-in closet and a bathroom with two vanities. The other bedrooms share a bathroom.

Floor Plans

  • Main Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 1,364 sq. ft.
  • 1st Floor: 1,364 sq. ft.
  • Covered Patio: 260 sq. ft.
  • Porch, Combined: 260 sq. ft.
  • Porch, Rear: 122 sq. ft.
  • Porch, Front: 138 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2

Foundation Type

    • Standard Foundations: Monolithic Slab, Slab
    • Optional Foundations: Crawl

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 40' 0"
  • Depth: 46' 0"
  • Max ridge height: 19' 3"

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof

  • Primary Pitch: 10 on 12
  • Secondary Pitch: 3 on 12
  • Framing Type: Stick And Truss
