Plan 135180GRA
3-Bed Shop House with 2400 Square Foot Garage
Heated S.F.
1,844
Beds
3
Baths
2.5
Stories
1
Cars
3
Flyer
What's Included
Floor Plan
PRINT PLANS
Main Level
Reverse Floor Plan
3-Bed Shop House with 2400 Square Foot Garage - 135180GRA floor plan - Main Level
Main Level - Basement Stairs Location
Reverse Floor Plan
3-Bed Shop House with 2400 Square Foot Garage - 135180GRA floor plan - Main Level - Basement Stairs Location
Plan Details
  • Board and batten siding stretches upward on this 3-bedroom barndo-style shop house plan with an oversized 2,400 square foot garage.
  • A front porch - 30' wide and 8' deep - greets you at the front door which opens to reveal an open and vaulted living space combining the living, dining, and kitchen areas. The island anchors the kitchen and offers an eating bar, while a corner pantry increases storage space.
  • The master bedroom occupies the right wing of the design and includes a 5-fixture bathroom with a walk-in closet.
  • Bedrooms 2 and 3 share a full bathroom and a nearby den provides a quieter space to relax, read, or work from home.
  • The 2,400 square foot garage has a 14' by 8' overhead door and a 10' by 8' overhead door. A person door on the left gets you in and out as well. The garage is a whopping 59'1"-deep, giving you plenty of space for a workshop or hobby equipment.
  • The exterior finish is spec'd for corrugated metal siding.
  • Related Plans: Get an alternate version with house plans 135054GRA, 135085GRA, 135215GRA and 135225GRA.
What's Included
  • All elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
