3500 Square Foot Barndominium-Style House with Home Office and Oversized Side Entry Garage and Shop

Plan 135218GRA

  • 3,502

    Heated s.f.

  • 3

    Beds

  • 2.5+

    Baths

  • 2

    Stories

  • 3

    Cars

  • Enjoy the convenience of blending your work and living spaces with this 3-bedroom, Barndominium-style (stick framed) house plan. The wraparound porch and deck are ideal to take advantage of your views across your side-sloping lot.
  • The side-entry garage / shop totals 2,585 square feet with 3 overhead doors, including an oversized 12' by 14' in the center bay.
  • Minimal walls between the kitchen, dining area, and living room create the open-concept layout many desire. The spacious island kitchen delivers plenty of storage space with the nearby walk-in pantry.
  • A quiet den can be found just off the entryway and an office is located in the back of the garage.
  • The master suite with five-fixture bath and walk-in closet is the only bedroom on the main floor. Upstairs, you'll find two more bedrooms with walk-ins that share a bath and a loft that overlooks the living room below.
  • The exterior finish is spec'd for corrugated metal siding.
  • Related Plan: Get a front-entry garage with house plan 135108GRA and 135047GRA.

  • All elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
