Plan 8165LB

4-Plex with Clean Lines

Heated S.F.
4,108
Units
4
Width
Depth

Floor Plan

Plan 8165LB

Basement
Basement
Main Level
Main Level
2nd Floor
2nd Floor

Plan 8165LB

M-F 9am-5pm EST |

1-203-761-8500

Basement

Plan 8165LB: 4-Plex with Clean Lines - Floor Plan - Basement

Main Level

Plan 8165LB: 4-Plex with Clean Lines - Floor Plan - Main Level

2nd Floor

Plan 8165LB: 4-Plex with Clean Lines - Floor Plan - 2nd Floor

Plan Details

  • This four unit house plan has very clean lines and delivers four units in a single rectangular cost-effective footprint.
  • Each unit has 494 square feet on each of the main living floors and an extra 39 square feet on the lower level where the garage is.
Unit A
Heated Area
1,027Sq. Ft.
39 Sq. Ft. LL
494 Sq. Ft. 1st
498 Sq. Ft. 2nd
Beds
2Beds
Baths
2Full Baths
1Half Bath
Cars
Drive Under
417 Sq. Ft.
Dimensions
19'width
26'depth
32' 7"height
Unfinished Areas
417 Sq. Ft. Garage
