Plan 42245WM

Affordable Cottage Home Plan

Heated S.F.
1,692
Beds
4
Baths
2.5
Stories
2
Cars
2

Floor Plan

Plan 42245WM

Main Level
Main Level
2nd Floor
2nd Floor

Plan 42245WM

M-F 9am-5pm EST |

1-203-761-8500

Main Level

Plan 42245WM: Affordable Cottage Home Plan - Floor Plan - Main Level - Cottage, Country, Traditional

2nd Floor

Plan 42245WM: Affordable Cottage Home Plan - Floor Plan - 2nd Floor - Cottage, Country, Traditional

Plan Details

  • This flexible cottage house plan comes in both this 4 bedroom version and a 3 bedroom one (house plan 42244DB). Both feature a 7' deep covered front porch giving you a place to enjoy the outdoors in style.
  • At under 1,692 sq. ft., this house plan is cost-effective to build and uses simplified construction while maintaining architectural integrity.
  • This was designed with a minimal amount of wasted space. Note the nearly complete lack of hallways.
  • This open concept house plan gives you an open living room, dining room and kitchen arrangement. The result is a home that feels larger than it is.
  • Optional stairs lead to a basement and an optional door gives you access to the home through the powder room.
  • Related Plan: For a 3 bedroom version, see house plan 42244DB.

What's Included

  • Front elevation and construction notes
  • Rear and side elevations
  • Floor plan including electrical, window and door sizes, floor joist span direction and ceiling type notes (9' ceiling, vault, etc.)
  • Second floor plan (if applicable) with the same details as the first level floor plan
  • Typical wall section
  • Typical foundation details
  • Roof plan showing roof pitches, ridges and valleys, noted as 2" x 8" rafter or optional roof trusses
  • Foundation plan
  • Full building section
View Sample Plan

What's Not Included

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Starting at

Ready to Get Started?

Select your plan set options before checkout.

Price Match Guarantee
What's included?

Modify this Plan

Receive a free modification quote within 3 business days.

Start with a Cost Report

Calculate the cost to build & furnish your home.

Square Footage Breakdown

Total Heated Area

1,692 sq. ft.

1st Floor

1,090 sq. ft.

2nd Floor

602 sq. ft.

Porch, Front

140 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

2

Half bathrooms

1

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

41' 0"

Depth

46' 0"

Max Ridge Height

23' 0"

Garage

Type

Attached

Area

462 sq. ft.

Count

2 Cars

Entry Location

Front

Ceiling Heights

First Floor

9'

Second Floor

8'

Roof Details

Primary Pitch

9 on 12

Framing Type

Stick

Architectural Style

Cottage

Country

Traditional

Special Features

Laundry - Main Level

Master Suite - 1st Floor

Square Footage Breakdown

Total Heated Area

1,692 sq. ft.

1st Floor

1,090 sq. ft.

2nd Floor

602 sq. ft.

Porch, Front

140 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

2

Half bathrooms

1

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

41' 0"

Depth

46' 0"

Max Ridge Height

23' 0"

Garage

Type

Attached

Area

462 sq. ft.

Count

2 Cars

Entry Location

Front

Ceiling Heights

First Floor

9'

Second Floor

8'

Roof Details

Primary Pitch

9 on 12

Framing Type

Stick

Architectural Style

Cottage

Country

Traditional

Special Features

Laundry - Main Level

Master Suite - 1st Floor
