Affordable Ranch Home Plan with Gabled Roof
Heated S.F.
1,928
Beds
3
Baths
2.5
Stories
1
Cars
3
Videos
What's Included
Plan Details
  • A gabled roof makes this ranch home affordable to build without sacrificing a bit of curb appeal.
  • The large front porch welcomes you inside where a vaulted entry leads you to the main living area.
  • A formal dining room lies just to your right with the great room directly ahead.
  • The kitchen features an island that blends with the nook to create a straight line of vision throughout the main living area.
  • Vaulted ceilings and a fireplace make the area cozy without being too formal.
  • The master suite lies to the back right of the home and pleases with a tray ceiling, walk-in closet and dual sinks.
  • The remaining two bedrooms lie in front of the master and enjoy access to the full bath just outside the bedroom doors.
  • A 3-stall, double stack garage completes this ranch home plan.
What's Included

Plans include the following:

  • General Notes
  • Rendering
  • Elevations
  • Fully dimensioned floor plans
  • Foundation
  • Typical wall section & stair section
  • Cross section
  • Cabinet elevations
  • Electrical Plan
  • Roof plan

What is NOT included in the plans:

  • Architectural or Engineering Stamp
  • Site Plan
  • Mechanical Drawings (location of heating and air equipment and duct work)
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations)
  • Framing layouts with beam sizes and locations
  • Energy calculations
