All the Bells and Whistles

Plan 66328WE

  • 8,899

    Heated s.f.

  • 5

    Beds

  • 5.5+

    Baths

  • 2

    Stories

  • 4

    Cars

  • Spacious and grand, this lovely Florida home plan has every luxurious amenity you can think of.
  • Stunning ceiling treatments, a residential elevator and several wet bars are but a few of the impressive details.
  • A two-sided fireplace warms both the huge living room and the library with its coffered ceiling.
  • The informal area of the home is huge and all open concept, giving you sweeping views everywhere you look.
  • Choose from a first floor or second floor master suite, each with a separate sitting area.
  • Two additional bedroom suites on the second floor each have access to covered balconies.
  • You also have both a great room and a game room with wet bar that has sliding glass doors on two walls that lead out to the upper covered lanai.
  • The ground floor outdoor area is no less luxurious and has a big outdoor kitchen and a fire pit area.
  • The reflection pool can be enjoyed from the living room curved window bay.

Elevations

Drawn at 1/8″ to 1/4″ = 1′-0″ Scale, and Includes:
  Material Labels
  Floor-to-Floor Heights
  Roof Slope Indicators


Floor Plans

Drawn at 1/8″ to 1/4″ = 1′-0″ Scale, and Includes:
  Door and Window Sizes
  Completely Dimensioned Floor Plan
  Room Labels and Interior Room Sizes


Electrical Layouts

Building Section Markers
All Electrical Outlets, Fixtures, and Switching


*Slab Plan

Drawn at 1/8″ to 1/4″ = 1′-0″ Scale, and Includes:
Floor and Deck Joist Size and Spacing
Rough-in Plumbing Location (if applicable)
Mechanical Equipment Locations (if applicable)
Electrical Locations (if applicable)



Roof Design Plan

Drawn at 1/8″ to 1/4″ = 1′-0″scale, and Includes:
All Beam and Header Heights and Locations
All Hips, Gables, Ridges, and Valleys
Building Section Markers


Building Sections

Drawn at 1/8″ to 1/4″ = 1′-0″ Scale, and Includes:
Floor Joist Size and Spacing
Floor-to-Floor Heights
Non-Typical Plate Heights Indicated


Typical Wall Sections

Drawn at 1/8″ to 1/2″ = 1′-0″ Scale, and Includes:
All Labels Indicating Wall Construction
Foundation Wall Thickness and Reinforcing
Insulation Type and Thickness


Miscellaneous Notes and Details

Miscellaneous General Notes
Stairway details (if applicable)



*We do provide a slab plan, however, the structural foundation plan is to be provided by the structural engineer selected by your builder or yourself. This is done because our slab plan cannot anticipate the variations in soil, footings and other conditions per your specific site. We provide the design of the roof as well, however, the truss layouts need to be provided by a truss engineer or your lumber company. Your builder can provide these contacts for you.  Please keep in mind that these are additional expenses outside of the cost of the original plan that you purchase from us.


These items are NOT included:


Architectural or Engineering Stamp - handled locally if required

Site Plan - handled locally when required

Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this

Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this

Energy calculations - handled locally when required

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
All the Bells and Whistles - 66328WE floor plan - Main Level

2nd Floor

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
All the Bells and Whistles - 66328WE floor plan - 2nd Floor

Plan details

Square Footage Breakdown

  • Total Heated Area: 8,899 sq. ft.
  • 1st Floor: 6,041 sq. ft.
  • 2nd Floor: 2,858 sq. ft.
  • Lanai: 2,477 sq. ft.
  • Balcony / Veranda: 447 sq. ft.
  • Entry: 296 sq. ft.

Beds/Baths

  • Bedrooms: 5
  • Full bathrooms: 5
  • Half bathrooms: 2

Foundation Type

  • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): Block / CMU (main floor)
  • Optional Type(s): 2x6

Dimensions

  • Width: 134' 4"
  • Depth: 132' 8"

Garage

  • Type: Attached
  • Area: 1482 sq. ft.
  • Count: 4 Cars

Ceiling Heights

  • Floor / Height: First Floor / 12' 0" Second Floor / 10' 0"

Roof Details

  • Primary Pitch: 8 on 12
  • Framing Type: Truss

Architectural Style

Special features

Plan Collections

All the Bells and Whistles

  • 8,899

    Heated s.f.

  • 5

    Beds

  • 7

    Baths

  • 2

    Floors

  • 4

    Car garage

Buy This Plan
  • Reproducible Set $5,500
