Attractive Duplex

Plan 60551ND

  • 1,704

    Heated s.f.

  • 2

    Units

  • 82' 8"

    Width

  • 34'

    Depth

  • This attractive duplex has two bedrooms and an open floor plan. Each unit has 2 bedrooms and 1 bathroom and gives you 852 sq. ft. of living area.
  • A grilling patio in the rear can be enlarged by your builder to suit your lot.
  • Use one unit for rental income or house family members right next door.
  • This duplex comes in two elevations - take your pick!

Each plan set includes the following:

  • Foundation Plan** (1/4″ or 1/2″ = 1′)
  • Floor Plans (1/4″= 1′)
  • Set of Elevations (1/4″= 1′)
  • Miscellaneous Details (3/4″ = 1′)
  • An electrical diagram showing a birdseye view of rooms with lights, fans to switches
These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Unit Details

Unit 1
852 Sq. Ft.
Unit 2
852 Sq. Ft.

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Attractive Duplex - 60551ND floor plan - Main Level

Plan details

Square Footage Breakdown

  • Total Heated Area: 1,704 sq. ft.
  • 1st Floor: 1,704 sq. ft.

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 2

Foundation Type

  • Standard Foundations: Crawl, Slab

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 82' 8"
  • Depth: 34' 0"
  • Max ridge height: 18' 4"

Garage

  • Type: Attached
  • Area: 358 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof Details

  • Primary Pitch: 7 on 12
  • Framing Type: Stick

Architectural Style
