Bi-Generational Beauty

Plan 21962DR

  • 1,979

    Heated s.f.

  • 2

    Units

  • 60' 0"

    Width

  • 42' 0"

    Depth

  • This charming bi-generational beauty allows multiple generations barrier-free access to both suites. A shared entry provides interior access to both suites, private but within easy access if help or company is needed. Each suite enjoys private backyard access.
  • The family suite has two bedrooms oriented to the front of the home with the activities area oriented to the back. The grandparent suite is a single-bedroom unit, complete with its own kitchen, dining room, living room and laundry.
  • The plan includes an unfinished basement ready for expansion.
  • Note: Please allow 15 business days for delivery.

Each plan includes the following:

* 4 Elevations
* Foundation Plan
* Main Floor Plan
* Upper Floor Plans (if applicable)
* Roof Plan
* Truss Diagrams & Building Section
* Construction Details
* Typical Wall Section

These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical and Electrical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required


Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Bi-Generational Beauty - 21962DR floor plan - Main Level

Plan details

Square Footage Breakdown

  • Total Heated Area: 1,979 sq. ft.
  • 1st Floor: 1,979 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2

Foundation Type

  • Standard Foundations: Basement
  • Optional Foundations: Slab, Crawl, Walkout, Daylight

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 60' 0"
  • Depth: 42' 0"
  • Max ridge height: 21' 6"

Ceiling Heights

  • Floor / Height: First Floor / 8' 0"

Roof Details

  • Framing Type: Truss

Special features

Plan Collections

Bi-Generational Beauty

  • 1,979

    Heated s.f.

  • 2

    Units

  • 60' 0"

    Width

  • 42' 0"

    Depth

Buy This Plan
  • PDF - Single-Build $1,420
  • Reproducible Set $1,420
  • 5 Sets + PDF $1,545
  • CAD - Single-Build $2,020
  • View all purchase option online

About This Plan

  • This charming bi-generational beauty allows multiple generations barrier-free access to both suites. A shared entry provides interior access to both suites, private but within easy access if help or company is needed. Each suite enjoys private backyard access.
  • The family suite has two bedrooms oriented to the front of the home with the activities area oriented to the back. The grandparent suite is a single-bedroom unit, complete with its own kitchen, dining room, living room and laundry.
  • The plan includes an unfinished basement ready for expansion.
  • Note: Please allow 15 business days for delivery.
