Plan 59201ND
Breathtaking Lake Views
Heated S.F.
6,541
Beds
3-5
Baths
4 - 5
Stories
1
Cars
2
What's Included
Plan Details
  • Upon entering this lake home plan, a breathtaking view of the lake can be seen through the floor length windows.
  • A vaulted ceiling in the great room opens through to the hearth room and kitchen creating a wonderful ambiance to enjoy the stone fireplace.
  • The private den area features a pass through fireplace to the secluded sitting area, both accessible to the screened porch with French doors.
  • The downstairs master bedroom has a luxurious master bath including 'his and her' walk-in closets.
  • The upstairs has two private suites with access to the rear deck and a balcony overlooking the Great room below.
What's Included
  • Foundation Plan** (1/4″ or 1/2″ = 1′)
  • Floor Plans (1/4″= 1′)
  • Set of Elevations (1/4″= 1′)
  • Miscellaneous Details (3/4″ = 1′)
  • An electrical diagram showing a birdseye view of rooms with lights, fans to switches
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Breathtaking Lake Views

  • 6,541

    Heated s.f.

  • 3-5

    Beds

  • 4 - 5

    Baths

  • 1

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

  • 2nd Floor

  • Lower Level

Plan Details

Square Footage Breakdown

  • Total: 6,541 sq. ft.
  • Lower Level: 1,248 sq. ft.
  • 1st Floor: 3,364 sq. ft.
  • 2nd Floor: 1,929 sq. ft.

Dimensions

  • Width: 88' 8"
  • Depth: 70' 5"
  • Max ridge height: 31' 4"

Beds/Baths

  • Bedrooms: 3, 4, or 5
  • Full bathrooms: 4 or 5

Garage

  • Type: Carport
  • Area: 702 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Crawl, Slab
    • Optional Foundations: Basement, Walkout

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 9' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 12 on 12
  • Framing Type: Stick
