Coastal Florida Style House Plan with 5 Bedrooms and 3-Car Garage

Name: Plan 65797BS: Coastal Florida Style House Plan with 5 Bedrooms and 3-Car Garage
Brand: Architectural Designs
SKU: 65797BS
Price: 4501.0 USD
Availability: InStock

Heated S.F.

4,501

Beds

Baths

4.5

Stories

Cars

Floor Plan

Plan Details

This sprawling 4,501 square foot coastal Florida-style residence offers five bedrooms, four full bathrooms, and one half-bath, all anchored by a generous 1,001 square foot three-car side-entry garage.
Upon arrival, the elegant facade welcomes guests into a thoughtfully designed single-level layout that emphasizes seamless transitions between refined indoor living and expansive outdoor leisure spaces.
The heart of the home features a sophisticated open-concept floor plan where the gourmet kitchen, complete with a walk-in pantry, flows effortlessly into the formal dining room and a sun-drenched breakfast nook.
The primary suite is positioned for optimal privacy and includes a dedicated sitting area, serving as a tranquil retreat tucked away from the four additional secondary bedrooms.
Designed for the ultimate lifestyle, the massive 969 square foot lanai acts as an extension of the living area, featuring an integrated outdoor kitchen and fireplace for year-round entertaining.
Additional practical amenities include a private library or study for remote work, a dedicated mudroom for seamless organization, and a convenient main-level laundry room.
