Plan 3935ST
Color and Dimension
Heated S.F.
2,160
Beds
3
Baths
2.5
Stories
2
Cars
2
What's Included
Plan Details
  • Arched windows, a brick fa'ade, a covered porch and wood trim add color and dimension to this exciting home.
  • The master bedroom, with sloped ceiling and luxurious bath, is located for easy access to the second floor while enjoying the convenience of the first floor.
  • The Great Room with gas fireplace and 17' ceiling height, the kitchen with a breakfast bar that opens to the Great Room and the bayed Breakfast area form to create a wonderful family center.
  • The formal Dining Room provides additional space for special occasion dining. The landing at the u-shaped stairs overlooks the Great Room as does the balcony at the second floor.
  • Two additional bedrooms and a bath complete this beautiful home plan.
What's Included
  • General notes and specifications
  • Front, rear and side elevations at (1/4" scale)
  • Foundation plan (1/4" scale) indicating beam and column sizes along with lower level framing
  • Reinforced foundation and footing details
  • First floor plan (1/4" scale) includes all necessary framing information, window rough openings, beam sizes and framing details for specialized areas
  • Stairs, sections, cabinet layouts, window flashing and miscellaneous details necessary for understanding of construction methods
  • Roof plan (1/8" scale) indicating pitches and wall height as well as truss profiles indicating heel heights and raised ceiling areas
  • Wall section indicating standard materials and detailing for typical wall construction
These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Color and Dimension

  • 2,160

    Heated s.f.

  • 3

    Beds

  • 2.5

    Baths

  • 2

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 2,160 sq. ft.
  • 1st Floor: 1,541 sq. ft.
  • 2nd Floor: 619 sq. ft.

Dimensions

  • Width: 58' 0"
  • Depth: 44' 4"
  • Max ridge height: 29' 11"

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 417 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Basement
    • Optional Foundations: Crawl

Exterior Walls

  • Standard Type(s): 2x4

Ceiling Heights

  • Floor / Height: First Floor / 8' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 8 on 12
  • Secondary Pitch: 12 on 12
  • Framing Type: Truss
