Compact Ranch Design

Plan 2003GA

  • 1,381

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Stories

  • 2

    Cars

  • With its front porch, planter, and combination of siding, wood shingles, and stone, this compact ranch is warm and irresistible. With a truss roof system and simple design, this cost-effective plan is perfect for the budget-conscious.
  • Though only 1381 square feet, you'll find a 10'x15' kitchen, a 16'x12' master bedroom, and two spacious secondary bedrooms.
  • Beyond the front porch and through the entry is the family room with a 12' high ceiling. Its focal point is a fireplace with a TV niche above. To the right is the dining room and kitchen. The angled breakfast bar is open to both the family and dining rooms.
  • The master suite features his and hers walk-in closets and a full-featured bath including a whirlpool tub and shower. The secondary bedrooms measuring 11'x12'-8' and 11'x12' share the second bath.
  • Other than the family room, all other ceiling heights are 9'.
  • Related Plan: Get a smaller version with house plan 2001GA (1,197 sq. ft.).
