Compact Starter House Plan
Each plan set includes the following:
Plan: Complete with dimensions,
dimensioned plumbing, referenced details, General Notes and Schedules.
- Elevations: Minimal four completed elevations with dimensions, notes
and material call outs. Also exterior details where applicable.
Plan(s): Complete with dimensions and notes
of all elements. On our high-end plans we provide architectural and structural
floor plans, as typical part of our sets to avoid clatter and for easy
Plan: Complete with roof pitches
overhangs and notes for special condition also dimensions on any special
condition as per plan.
Sections: Where applicable, building sections
are included. The quantity of these drawings is determined by the plan set
- Details: Interior and Exterior details as require per plan. Common
details are: Applicable Cornice (Eve) and Special Details designed directly
from the plan (not typical details that are reused for every plan produced). We
do this to improve the accuracy and integrity that should be expected from quality
set of plans.
Elevations: Some sets include interior Kitchen,
Bathrooms and other significant detailed plan specific areas.
Framing Plan: Engineered truss layout from a local
truss company. All hangers, connectors and or special details are shown. Since
local codes and conditions very, this plan is for reference only.
Framing Plan: Only were needed. Engineered floor
truss layout from a local truss company. All hangers, connectors and or special
details are shown. Since local codes and conditions very, this plan is for
Sections: Complete with layout, light
fixtures, outlets, legend and notes.
Plan: Complete with layout, Light
fixtures, Outlets and legend.
Plan: Provided with block concrete
masonry unit plans only. Lintel sizes and details for all exterior openings.
Since local codes and conditions very, this plan is for reference only.
Details: Including wall sections and all
framing details needed per plans. Since local codes and conditions very, this
plan is for reference only.
