Plan 69536AM

Contemporary Home Plan with Lower Level Game Room

Pageloader

Contemporary Home Plan with Lower Level Game Room

Plan 69536AM

  • 3,097

    Heated s.f.

  • 3

    Beds

  • 2.5

    Baths

  • 2

    Stories

  • 2

    Cars

  • Ideal for the retiree or empty-nester, this Contemporary home plan lets you live all on one level and have the finished lower level for guests or family members when they visit.
  • A built-in desk in the office has views of the stairs going down.
  • Cozy up to the corner fireplace in the great room or step out onto the rear deck through sliding glass doors.
  • The kitchen is large with a big island and a corner window by the sink.
  • The main floor master suite has a walk-in closet, access to the deck and a big soaking tub.
  • Entertain in the finished lower level complete with wet bar and another corner fireplace.
  • Each of the two bedrooms on this level has its own walk-in closet.

Exterior Elevations: In addition to the front exterior, your drawing set will include drawings of the rear and sides of your house as well. These drawings give notes on exterior materials and finishes. Particular attention is given to cornice detail, brick and stone accents, or other finish items that make your home unique.

Foundation Plan: The foundation page dimensions, concrete walls, footings, pads, posts, beams, bearing walls, and any stepped foundation information along with any retaining wall info (schematic only). A typical wall section for the home is also usually included on this page (if not, it is elsewhere in your plan set, as space allows). If your plan features a poured concrete slab rather than a basement or crawlspace, the foundation page shows footings and details for the slab, and includes plumbing locations.

Floor Plan(s): Exterior and interior wall framing, and windows/doors are dimensioned. Room sizes are indicated and any beams, posts and structural bearing points are called out. The floor plans include an electrical legend, and electrical fittings, lights and outlets are shown. Floor Plans will also indicate cross–section details (provided on the sections page) and show any special framing details applicable to the design. Cabinet elevations are included for kitchen and bathrooms; some designs feature cabinet elevations for design–related built–ins too.

Building Sections: Building sections show changes in floor, ceiling, or roof height, and the relationship of one level to another. Our section pages also show how the stairs are calculated (if there are some!) and depict roof and foundation members. We try and draw sections to show the most useful information — choosing locations where there are elements you or your contractor might need clarification on.

IMPORTANT NOTE:  Sections and elevations depict the standard foundation only.

Roof Plan: Roof framing or truss directions are shown, slope directions are indicated and structural members are sized and called out if applicable. The gravity loads used to calculate the rafters, beams and posts are indicated , and we also show gutters, downspouts, and any roof venting required for your home.

Notes and Details Page(s): Your home comes detailed to meet the requirements of the latest adopted version of the ‘International Residential Code’, and our notes and details pages outline all the elements applicable to the design of your home. Compliance with further standards may need to be incorporated into your plan set, depending on the requirements of your building department — these are usually done locally.

Floor Plan

Plan details



Contemporary Home Plan with Lower Level Game Room

  • 3,097

    Heated s.f.

  • 3

    Beds

  • 3

    Baths

  • 2

    Floors

  • 2

    Car garage

Buy This Plan
  • Digital Study Set $1,028
  • PDF - single-use $1,378
  • 5 Sets $1,528
  • 5 Sets PLUS $1,578
  • CAD - multi-use $2,756
  • View all purchase option online

About This Plan

  • Ideal for the retiree or empty-nester, this Contemporary home plan lets you live all on one level and have the finished lower level for guests or family members when they visit.
  • A built-in desk in the office has views of the stairs going down.
  • Cozy up to the corner fireplace in the great room or step out onto the rear deck through sliding glass doors.
  • The kitchen is large with a big island and a corner window by the sink.
  • The main floor master suite has a walk-in closet, access to the deck and a big soaking tub.
  • Entertain in the finished lower level complete with wet bar and another corner fireplace.
  • Each of the two bedrooms on this level has its own walk-in closet.

Floor Plans

  • Main Level

  • Lower Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 3,097 sq. ft.
  • Lower Level: 1,265 sq. ft.
  • 1st Floor: 1,832 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2
  • Half bathrooms: 1

Foundation Type

    • Standard Foundations: Walkout

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 72' 0"
  • Depth: 56' 6"
  • Max ridge height: 23' 4"

Garage

  • Type: Attached
  • Area: 540 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Ceiling Heights

  • Floor / Height: Lower Level / 10' 0" First Floor / 10' 0"

Roof

  • Framing Type: Truss
