Craftsman Ranch House Plan with Large Game Room

Plan 135000GRA

  • 3,151

    Heated s.f.

  • 3

    Beds

  • 2.5

    Baths

  • 1

    Stories

  • 3

    Cars

  • A tapered column on stacked stone supports the charming front porch of this Craftsman Ranch house plan. The open concept floor plan is filled with natural light and seamlessly flows onto the back patio for additional outdoor living space.
  • A cathedral ceiling above the great room makes the space feel even larger, and the hexagon-shaped kitchen is anchored by an angled island with a double-bowl sink.
  • The large game room is an entertainer's dream and can be shut off from the remainder of the home. Windows line the rear wall, and a built-in wet bar sits next to a half bath.
  • The 3-car garage offers entry from the front of the home, and provides a mudroom with built-in lockers just inside. A pocket door across the hall reveals the laundry room with a utility sink.
  • Three bedrooms occupy the left side of the home with the largest reserved for the homeowner. The master bathroom features a tile shower, whirlpool tub, and a walk-in closet.

  • All elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Craftsman Ranch House Plan with Large Game Room - 135000GRA floor plan - Main Level

Craftsman Ranch House Plan with Large Game Room

  • 3,151

    Heated s.f.

  • 3

    Beds

  • 2.5

    Baths

  • 1

    Floors

  • 3

    Car garage

Floor Plan

  • Main Level

Plan Details

Square Footage Breakdown

  • Total: 3,151 sq. ft.
  • 1st Floor: 3,151 sq. ft.

Dimensions

  • Width: 85' 3"
  • Depth: 73' 5"
  • Max ridge height: 22' 11"

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 1096 sq. ft.
  • Count: 3 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Slab
    • Optional Foundations: Walkout, Crawl, Basement

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof

  • Primary Pitch: 10 on 12
  • Secondary Pitch: 4 on 12
